TRIAN AFX Midi

UPCOMING
TRIAN AFX MidiTRIAN AFX Midi
TRIAN AFX MidiTRIAN AFX Midi

LB6020.871-EN

CEUKCAIK08IP66Class I
Variants
Light distribution
[ASYM-FW] 60⁰, [ASYM-SD] 118⁰x45⁰
Delivered lumens flux
614 - 2056 lm
Rated input power
8 - 17 W
Colour temperature
2200 K CRI 80, 2700 K CRI 80, 3000 K CRI 80, 4000 K CRI 70
BUG rating
B0-U2-G1, B0-U1-G0
Lifetime L90B50 (hour)
>102, 000
Lifetime L80B50 (hour)
>102, 000
Options
Control
On/Off, DALI
Product colours
BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
Height
1.15m
Extras
Light output
Constant light output
Luminaire body options
Double powder coating

Technical details



Certificates
CE, UKCA
Mounting
Surface mountable
Housing
Corrosion resistant, extruded, marine grade aluminum housing
Finishing
Chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (AISI 304 / EN 1.4301 grade)
Gasket
Liquid silicone
Lens / Reflector
PMMA lens with high optical efficiency
Glass / Diffusor
Tempered safety glass
Impact protection
IK08
Ingress protection
IP66
Input voltage
220-240V 50/60Hz
Insulation class
Class I
Weight
8.7 kg
LED module
High power LEDs on metal-core PCB
Driver
Integral LED driver
Driver surge protection
2/2 kV
Power factor
> 0.90
Through wiring
Single cable entry
Operating temperature
-40...50°C
Cable
0.5 m of flexible cable

Downloads


Variants


Light distribution
Asymmetric Forward
[ASYM-FW] Asymmetric Forward - 60⁰
Asymmetric Side
[ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux
614 lm
658 lm
746 lm
831 lm
891 lm
970 lm
1010 lm
1039 lm
1072 lm
1149 lm
1178 lm
1302 lm
1303 lm
1396 lm
1582 lm
1693 lm
1814 lm
2056 lm
Rated input power
8 W
12 W
17 W
Colour temperature
2200 K CRI 80
2700 K CRI 80
3000 K CRI 80
4000 K CRI 70

Variant code

Light distribution

Delivered lumens flux

Rated input power

Colour temperature

Control


Variant code: LB6020.871-EN-ASYM-SD-350-740
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 746 lm
Rated input power: 8 W
Colour temperature: 4000 K CRI 70
Control: On/Off
LB6020.871-EN-ASYM-SD-350-740
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
746 lm
Rated input power
8 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
93 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-350-822
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 614 lm
Rated input power: 8 W
Colour temperature: 2200 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-SD-350-822
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
614 lm
Rated input power
8 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
77 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-350-827
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 658 lm
Rated input power: 8 W
Colour temperature: 2700 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-SD-350-827
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
658 lm
Rated input power
8 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
82 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-350-830
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 658 lm
Rated input power: 8 W
Colour temperature: 3000 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-SD-350-830
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
658 lm
Rated input power
8 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
82 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-500-740
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 1010 lm
Rated input power: 12 W
Colour temperature: 4000 K CRI 70
Control: On/Off
LB6020.871-EN-ASYM-SD-500-740
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
1010 lm
Rated input power
12 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
84 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-500-822
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 831 lm
Rated input power: 12 W
Colour temperature: 2200 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-SD-500-822
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
831 lm
Rated input power
12 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
69 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-500-827
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 891 lm
Rated input power: 12 W
Colour temperature: 2700 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-SD-500-827
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
891 lm
Rated input power
12 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
74 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-500-830
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 891 lm
Rated input power: 12 W
Colour temperature: 3000 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-SD-500-830
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
891 lm
Rated input power
12 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
74 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-700-740
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 1302 lm
Rated input power: 17 W
Colour temperature: 4000 K CRI 70
Control: On/Off
LB6020.871-EN-ASYM-SD-700-740
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
1302 lm
Rated input power
17 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
77 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-700-822
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 1072 lm
Rated input power: 17 W
Colour temperature: 2200 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-SD-700-822
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
1072 lm
Rated input power
17 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
63 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-700-827
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 1149 lm
Rated input power: 17 W
Colour temperature: 2700 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-SD-700-827
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
1149 lm
Rated input power
17 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
68 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-SD-700-830
Light distribution: [ASYM-SD] Asymmetric Side - 118⁰x45⁰
Delivered lumens flux: 1149 lm
Rated input power: 17 W
Colour temperature: 3000 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-SD-700-830
Light distribution
[ASYM-SD] 118⁰x45⁰
Delivered lumens flux
1149 lm
Rated input power
17 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
68 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U2-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-350-740
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 1178 lm
Rated input power: 8 W
Colour temperature: 4000 K CRI 70
Control: On/Off
LB6020.871-EN-ASYM-FW-350-740
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
1178 lm
Rated input power
8 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
147 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-350-822
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 970 lm
Rated input power: 8 W
Colour temperature: 2200 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-FW-350-822
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
970 lm
Rated input power
8 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
121 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-350-827
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 1039 lm
Rated input power: 8 W
Colour temperature: 2700 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-FW-350-827
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
1039 lm
Rated input power
8 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
130 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-350-830
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 1039 lm
Rated input power: 8 W
Colour temperature: 3000 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-FW-350-830
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
1039 lm
Rated input power
8 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
130 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-500-740
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 1582 lm
Rated input power: 12 W
Colour temperature: 4000 K CRI 70
Control: On/Off
LB6020.871-EN-ASYM-FW-500-740
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
1582 lm
Rated input power
12 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
132 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-500-822
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 1303 lm
Rated input power: 12 W
Colour temperature: 2200 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-FW-500-822
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
1303 lm
Rated input power
12 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
109 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-500-827
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 1396 lm
Rated input power: 12 W
Colour temperature: 2700 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-FW-500-827
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
1396 lm
Rated input power
12 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-500-830
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 1396 lm
Rated input power: 12 W
Colour temperature: 3000 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-FW-500-830
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
1396 lm
Rated input power
12 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-700-740
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 2056 lm
Rated input power: 17 W
Colour temperature: 4000 K CRI 70
Control: On/Off
LB6020.871-EN-ASYM-FW-700-740
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
2056 lm
Rated input power
17 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
121 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-700-822
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 1693 lm
Rated input power: 17 W
Colour temperature: 2200 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-FW-700-822
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
1693 lm
Rated input power
17 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
100 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-700-827
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 1814 lm
Rated input power: 17 W
Colour temperature: 2700 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-FW-700-827
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
1814 lm
Rated input power
17 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LB6020.871-EN-ASYM-FW-700-830
Light distribution: [ASYM-FW] Asymmetric Forward - 60⁰
Delivered lumens flux: 1814 lm
Rated input power: 17 W
Colour temperature: 3000 K CRI 80
Control: On/Off
LB6020.871-EN-ASYM-FW-700-830
Light distribution
[ASYM-FW] 60⁰
Delivered lumens flux
1814 lm
Rated input power
17 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
8 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000

Accessories (To be ordered separately)


Accessories (To be ordered separately)


Extras


Constant light output

[CLO]

Constant light output

Light output
Double powder coating

[DPC]

Double powder coating

Luminaire body options

All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Asymmetric Forward
[ASYM-FW]

Asymmetric Forward

Asymmetric Side
[ASYM-SD]

Asymmetric Side

Drive current


350 mA
[350]

350 mA

500 mA
[500]

500 mA

700 mA
[700]

700 mA

Colour temperature


2200 K CRI 80
[822]

2200 K CRI 80

2700 K CRI 80
[827]

2700 K CRI 80

3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

Options

Control

Product colours


On/Off
[ONOFF]

On/Off

DALI
[DALI]

DALI

Product colours


Black
[HM1]

Black

Dark grey
[HM2]

Dark grey

Anthracite grey
[HM3]

Anthracite grey

Light grey
[HM4]

Light grey

White
[HM5]

White

Bronze
[HM6]

Bronze

Custom colour (Please specify RAL code)
[CC]

Custom colour (Please specify RAL code)
