    HELIOS 1 Module

    PHASED-OUT
    HELIOS 1 ModuleHELIOS 1 ModuleHELIOS 1 Module
    HELIOS 1 ModuleHELIOS 1 ModuleHELIOS 1 Module

    LP4036.771-EN

    CEUKCAIK07IP65Class I
    Variants
    Light distribution
    [SYM-3L] 360x65°
    Delivered lumens flux
    3990 - 4200 lm
    Rated input power
    38 W
    Colour temperature
    3000 K CRI 70, 4000 K CRI 70
    BUG rating
    B3-U0-G1
    Lifetime L90B10 (hour)
    >108, 000
    Lifetime L90B50 (hour)
    >108, 000
    Options
    Control
    On/Off, DALI, AutoDIM, StepDIM
    Product colours
    BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
    Extras
    Consult the factory
    120-277V 50/60Hz

    Technical details


    Certificates
    CE, UKCA
    Mounting
    Direct pole or side bracket mountable. Spigot: Ø60 mm x 100 mm
    Housing
    Corrosion resistant, marine grade aluminum housing
    Finishing
    Chromate conversion pretreatment followed by electrostatic powder coating
    Fasteners
    Stainless steel (AISI 304 / EN 1.4301 grade)
    Gasket
    Silicone
    Glass / Diffusor
    Custom Design PMMA Diffusor
    Impact protection
    IK07
    Ingress protection
    IP65
    Input voltage
    220-240V 50/60Hz
    Insulation class
    Class I
    Wind catching area (EPA)
    0.24 m²
    Weight
    4.86 kg
    LED module
    High power LEDs on metal-core PCB
    Driver
    Integral LED driver
    Driver surge protection
    10/6 kV
    Power factor
    > 0.95
    Through wiring
    Single cable entry
    Operating temperature
    -40...50°C
    Cable
    0.5 m of flexible cable
    Notes
    Please contact the sales department regarding this product's availability.

    Downloads

    Variants

    Light distribution
    Symmetric, Special effect: 3 lines
    [SYM-3L] Symmetric, Special effect: 3 lines - 360x65°
    Delivered lumens flux
    3990 lm
    4200 lm
    Rated input power
    38 W
    Colour temperature
    3000 K CRI 70
    4000 K CRI 70

    Variant code

    Light distribution

    Delivered lumens flux

    Rated input power

    Colour temperature

    Control

    Variant code: LP4036.771-EN-SYM-3L-700-730
    Light distribution: [SYM-3L] Symmetric, Special effect: 3 lines - 360x65°
    Delivered lumens flux: 3990 lm
    Rated input power: 38 W
    Colour temperature: 3000 K CRI 70
    Control: On/Off, DALI, AutoDIM, StepDIM
    Light distribution
    [SYM-3L] 360x65°
    Delivered lumens flux
    3990 lm
    Rated input power
    38 W
    Colour temperature
    3000 K CRI 70
    Luminaire efficacy
    105 lm/W
    Lamp
    16 LED
    MacAdam Ellipse
    5 SDCM
    BUG rating
    B3-U0-G1
    Lifetime L90B10 (hour)
    >108,000
    Lifetime L90B50 (hour)
    >108,000
    Variant code: LP4036.771-EN-SYM-3L-700-740
    Light distribution: [SYM-3L] Symmetric, Special effect: 3 lines - 360x65°
    Delivered lumens flux: 4200 lm
    Rated input power: 38 W
    Colour temperature: 4000 K CRI 70
    Control: On/Off, DALI, AutoDIM, StepDIM
    Light distribution
    [SYM-3L] 360x65°
    Delivered lumens flux
    4200 lm
    Rated input power
    38 W
    Colour temperature
    4000 K CRI 70
    Luminaire efficacy
    111 lm/W
    Lamp
    16 LED
    MacAdam Ellipse
    5 SDCM
    BUG rating
    B3-U0-G1
    Lifetime L90B10 (hour)
    >108,000
    Lifetime L90B50 (hour)
    >108,000

    Extras

    120-277V 50/60Hz

    [UNI]

    120-277V 50/60Hz

    Consult the factory

    Related products

    All flux and power values derived following appropriate IES, CIE and applicable standards.
    Descriptions
    Variants

    Light distribution

    Drive current

    Symmetric, Special effect: 3 lines
    [SYM-3L]

    Symmetric, Special effect: 3 lines

    Drive current

    700 mA
    [700]

    700 mA

    Colour temperature

    3000 K CRI 70
    [730]

    3000 K CRI 70

    4000 K CRI 70
    [740]

    4000 K CRI 70

    Options

    Control

    Product colours

    On/Off
    [ONOFF]

    On/Off

    DALI
    [DALI]

    DALI

    AutoDIM
    [AUTO]

    AutoDIM

    StepDIM
    [STEP]

    StepDIM

    Product colours

    Black
    [HM1]

    Black

    Dark grey
    [HM2]

    Dark grey

    Anthracite grey
    [HM3]

    Anthracite grey

    Light grey
    [HM4]

    Light grey

    White
    [HM5]

    White

    Bronze
    [HM6]

    Bronze

    Custom colour (Please specify RAL code)
    [CC]

    Custom colour (Please specify RAL code)
