D-LIGHT V2 AFX 2 Module

Name: D-LIGHT V2 AFX 2 Module
Brand: HEPER
SKU: LL2024.862-EN
Availability: InStock

UPCOMING

LL2024.862-EN

Downloads

Photometry files (IES)

1.26 MB ZIP

Photometry files (LDT)

1.05 MB ZIP

Technical drawing

0.09 MB PDF

Technical drawing (Image)

0.05 MB PNG

Certificate files

1.12 MB ZIP

Light distribution

[P4] 20x78°, [T1] 111x48°, [T2] 133x48°, [T2-2] 149x54°, [T3] 143x63°, [T4] 117x64°, [T5] 117°

Luminaire luminous flux

4045 - 9085 lm

Rated input power

34 - 67 W

CCT

3000K, 4000K

CRI

Ra70

Control

On/Off, DALI, AutoDIM, StepDIM

Product colours

Extras

Light output

Constant light output, Prismatic Glass

Consult the factory

Class II, 120-277V 50/60Hz

Luminaire efficacy

114 - 144 lm/W

Colour deviation

3 SDCM, 4 SDCM

BUG rating

B1-U0-G1, B2-U0-G1, B3-U0-G1, B2-U0-G0

Lifetime L90B10 (hour)

>102, 000

Housing

Marine grade aluminum housing

Driver

Integral LED driver

Input voltage

220-240V 50/60Hz

Notes

Prismatic Glass enhances visual comfort and alters light distribution, reducing delivered lumens by approximately 10%. For specifications with Prismatic Glass and photometry files, please contact the factory.

Configurator

Project name

Type

Quantity

Date

Note

Variant order code

LL2024.862-EN-_-_-_-_-EN-C1-_-_-___

Variants required

Variants

Light distribution

[P4]
Special pedestrian road distribution-right side traffic
20x78°

[T1]
Type I, Asymmetric, Side throw
111x48°

[T2]
Type II, Asymmetric, Side throw
133x48°

[T2-2]
Type II, Asymmetric, Side throw
149x54°

[T3]
Type III, Asymmetric, Side throw
143x63°

[T4]
Type IV, Asymmetric, Forward throw
117x64°

[T5]
Type V, Symmetric
117°

Rated input power

[350]
34 W

[500]
48 W

[700]
67 W

Colour temperature

[730]
3000 K CRI 70

[740]
4000 K CRI 70

Options

Control

[ONOFF]
On/Off

[DALI]
DALI

[AUTO]
AutoDIM

[STEP]
StepDIM

Product colours

[HM3]

Anthracite grey

[HM4]

Light grey

[CC]

Custom colour (Please specify RAL code)

Extras

Light output

[CLO]
Constant light output

[PG]
Prismatic Glass

Consult the factory

[C2]
Class II

[UNI]
120-277V 50/60Hz

Variants required

Technical details

Certificates

CE, UKCA, ENEC

Mounting

Direct pole or side bracket mountable. Spigot: Ø60 mm x 100 mm

Tilt angle

+15°/-15°

Finishing

Chromate conversion pretreatment followed by electrostatic powder coating

Fasteners

Stainless steel (AISI 304 / EN 1.4301 grade)

Gasket

EPDM gasket (Shore A 20-25)

Lens / Reflector

PMMA lens with high optical efficiency

Glass / Diffusor

Tempered safety glass

Impact protection

IK08

Ingress protection

IP66

Insulation class

Class I

Weight

7.3 kg

LED module

High power LEDs on metal-core PCB

Driver surge protection

10/6 kV

Power factor

< 0.95

Through wiring

Single cable entry

Operating temperature

-40...50°C

Cable

0.2 m of flexible cable

Extras

[CLO]

Constant light output

Light output

[PG]

Prismatic Glass

Light output

[C2]

Class II

Consult the factory

[UNI]

120-277V 50/60Hz

Consult the factory

Poles (To be ordered separately)

Cylindrical aluminum poles with flange plate

Diameter / Dimensions

Height

Spigot diameter

Diameter / Dimensions: Ø114mm, Ø122mm, Ø148mm, Ø165mm

Height: 3m, 4m, 5m, 6m, 7m, 8m, 9m

Spigot diameter: Ø114mm, Ø122mm, Ø148mm, Ø165mm

Conical aluminum poles with embedded base

Diameter / Dimensions

Height

Spigot diameter

Diameter / Dimensions: Ø114mm, Ø122mm, Ø148mm, Ø165mm, Ø180mm, Ø200mm

Height: 3m, 4m, 5m, 6m, 7m, 8m, 9m, 10m, 11m, 12m

Spigot diameter: Ø60mm, Ø76mm, Ø90mm

Conical aluminum poles with flange plate

Diameter / Dimensions

Height

Spigot diameter

Diameter / Dimensions: Ø114mm, Ø122mm, Ø148mm, Ø165mm, Ø180mm, Ø200mm

Height: 3m, 4m, 5m, 6m, 7m, 8m, 9m, 10m, 11m, 12m

Spigot diameter: Ø60mm, Ø76mm, Ø90mm

Cylindrical aluminium poles with embedded base

Diameter / Dimensions

Height

Spigot diameter

Diameter / Dimensions: Ø114mm, Ø122mm, Ø148mm, Ø165mm

Height: 3m, 4m, 5m, 6m, 7m, 8m, 9m

Spigot diameter: Ø114mm, Ø122mm, Ø148mm, Ø165mm

All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions

Variants

Light distribution

Drive current

[T1]

Type I, Asymmetric, Side throw

[T2]

Type II, Asymmetric, Side throw

[T2-2]

Type II, Asymmetric, Side throw

[T3]

Type III, Asymmetric, Side throw

[T4]

Type IV, Asymmetric, Forward throw

[T5]

Type V, Symmetric

[P4]

Special pedestrian road distribution-right side traffic

Drive current

[350]

350 mA

[500]

500 mA

[700]

700 mA

Colour temperature

[730]

3000 K CRI 70

[740]

4000 K CRI 70

Options

Control

Product colours

[ONOFF]

On/Off

[DALI]

DALI

[AUTO]

AutoDIM

[STEP]

StepDIM

Product colours

[HM3]

Anthracite grey

[HM4]

Light grey

[CC]

Custom colour (Please specify RAL code)
