C-LIGHT AFX 2 Module

NEW
C-LIGHT AFX 2 ModuleC-LIGHT AFX 2 Module
C-LIGHT AFX 2 ModuleC-LIGHT AFX 2 Module

LC2029.862-EN

CEUKCAIK08IP66Class I
Variants
Light distribution
[T5] , [T5] 117°
Delivered lumens flux
3285 - 9035 lm
Rated input power
34 - 67 W
Colour temperature
2200 K CRI 80, 2700 K CRI 80, 3000 K CRI 80, 4000 K CRI 70, 4000 K CRI 80
BUG rating
B2-U0-G0, B3-U0-G1, B3-U0-G0
Lifetime L90B10 (hour)
>102, 000
Lifetime L90B50 (hour)
>102, 000
Options
Control
On/Off, DALI, AutoDIM, StepDIM
Product colours
Anthracite greyLight greyCustom colour (Please specify RAL code)
Extras
Light output
Prismatic Glass
Consult the factory
Class II, 120-277V 50/60Hz
Luminaire body options
Double powder coating

Technical details



Certificates
CE, UKCA
Mounting
Catenary wire mounting
Housing
Corrosion resistant, die-cast, marine grade aluminum housing
Finishing
Chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (AISI 304 / EN 1.4301 grade)
Gasket
Liquid silicone
Lens / Reflector
PMMA lens with high optical efficiency
Glass / Diffusor
Tempered safety glass
Impact protection
IK08
Ingress protection
IP66
Input voltage
220-240V 50/60Hz
Insulation class
Class I
Weight
3.25 kg
LED module
High power LEDs on metal-core PCB
Driver
Integral LED driver
Driver surge protection
10/6 kV
Power factor
> 0.95
Through wiring
Single cable entry
Operating temperature
-40...50°C
Cable
1 m of halogen-free cable
Packing box dimensions
48*20*25 cm
Notes
This product can be supplied with Insulation class (Class II) upon request. Please contact factory. Prismatic Glass enhances visual comfort and alters light distribution, reducing delivered lumens by approximately 10%. For specifications with Prismatic Glass and photometry files, please contact the factory.

Downloads


Variants


Light distribution
Type V, Symmetric
[T5] Type V, Symmetric
Type V, Symmetric
[T5] Type V, Symmetric - 117°
Delivered lumens flux
3285 lm
4140 lm
4585 lm
4720 lm
5910 lm
5915 lm
6920 lm
7646 lm
9035 lm
Rated input power
34 W
48 W
67 W
Colour temperature
2200 K CRI 80
2700 K CRI 80
3000 K CRI 80
4000 K CRI 70
4000 K CRI 80

Variant code

Light distribution

Delivered lumens flux

Rated input power

Colour temperature

Control


Variant code: LC2029.862-EN-T5-350-822
Light distribution: [T5] Type V, Symmetric
Delivered lumens flux: 3285 lm
Rated input power: 34 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T5]
Delivered lumens flux
3285 lm
Rated input power
34 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
97 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-500-822
Light distribution: [T5] Type V, Symmetric
Delivered lumens flux: 4585 lm
Rated input power: 48 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T5]
Delivered lumens flux
4585 lm
Rated input power
48 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
96 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-700-822
Light distribution: [T5] Type V, Symmetric
Delivered lumens flux: 5915 lm
Rated input power: 67 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T5]
Delivered lumens flux
5915 lm
Rated input power
67 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
88 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-350-740
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 4720 lm
Rated input power: 34 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-350-740
Light distribution
[T5] 117°
Delivered lumens flux
4720 lm
Rated input power
34 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
139 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-350-827
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 4140 lm
Rated input power: 34 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-350-827
Light distribution
[T5] 117°
Delivered lumens flux
4140 lm
Rated input power
34 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
122 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-350-830
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 4140 lm
Rated input power: 34 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-350-830
Light distribution
[T5] 117°
Delivered lumens flux
4140 lm
Rated input power
34 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
122 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-350-840
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 4140 lm
Rated input power: 34 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-350-840
Light distribution
[T5] 117°
Delivered lumens flux
4140 lm
Rated input power
34 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
122 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-500-740
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 6920 lm
Rated input power: 48 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-500-740
Light distribution
[T5] 117°
Delivered lumens flux
6920 lm
Rated input power
48 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
144 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-500-827
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 5910 lm
Rated input power: 48 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-500-827
Light distribution
[T5] 117°
Delivered lumens flux
5910 lm
Rated input power
48 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
123 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-500-830
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 5910 lm
Rated input power: 48 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-500-830
Light distribution
[T5] 117°
Delivered lumens flux
5910 lm
Rated input power
48 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
123 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-500-840
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 5910 lm
Rated input power: 48 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-500-840
Light distribution
[T5] 117°
Delivered lumens flux
5910 lm
Rated input power
48 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
123 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-700-740
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 9035 lm
Rated input power: 67 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-700-740
Light distribution
[T5] 117°
Delivered lumens flux
9035 lm
Rated input power
67 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
134 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B3-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-700-827
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 7646 lm
Rated input power: 67 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-700-827
Light distribution
[T5] 117°
Delivered lumens flux
7646 lm
Rated input power
67 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B3-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-700-830
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 7646 lm
Rated input power: 67 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-700-830
Light distribution
[T5] 117°
Delivered lumens flux
7646 lm
Rated input power
67 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B3-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LC2029.862-EN-T5-700-840
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 7646 lm
Rated input power: 67 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LC2029.862-EN-T5-700-840
Light distribution
[T5] 117°
Delivered lumens flux
7646 lm
Rated input power
67 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B3-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000

Extras


Prismatic Glass

[PG]

Prismatic Glass

Light output
Class II

[C2]

Class II

Consult the factory
120-277V 50/60Hz

[UNI]

120-277V 50/60Hz

Consult the factory
Double powder coating

[DPC]

Double powder coating

Luminaire body options

All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Type V, Symmetric
[T5]

Type V, Symmetric

Drive current


350 mA
[350]

350 mA

500 mA
[500]

500 mA

700 mA
[700]

700 mA

Colour temperature


2200 K CRI 80
[822]

2200 K CRI 80

2700 K CRI 80
[827]

2700 K CRI 80

3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

4000 K CRI 80
[840]

4000 K CRI 80

Options

Control

Product colours


On/Off
[ONOFF]

On/Off

DALI
[DALI]

DALI

AutoDIM
[AUTO]

AutoDIM

StepDIM
[STEP]

StepDIM

Product colours


Anthracite grey
[HM3]

Anthracite grey

Light grey
[HM4]

Light grey

Custom colour (Please specify RAL code)
[CC]

Custom colour (Please specify RAL code)
