    SPARK B Duo

    UPCOMING
    IF Design Award 2023
    SPARK B DuoSPARK B DuoSPARK B Duo
    SPARK B DuoSPARK B DuoSPARK B Duo

    LB8061.529-EN

    CEUKCAIK07IP66Class III

    Downloads

    Variants
    Light distribution
    [M] 50°, [MN] 36°, [N] 24°, [S] 8°, [VN] 18°
    Delivered lumens flux
    736 - 1434 lm
    Rated input power
    16 - 20 W
    Colour temperature
    2700 K CRI 90, 3000 K CRI 90, 4000 K CRI 90
    Lifetime L90B50 (hour)
    >50000
    Options
    Product colours
    BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
    Height
    60cm, 90cm, Custom height (Please specify)
    Extras
    Light output
    Blue Color Filter, Green Color Filter, Honeycomb, Orange Color Filter, Red Color Filter, Yellow Color Filter
    Luminaire body options
    Double powder coating

    Technical details


    Certificates
    CE, UKCA
    Mounting
    Surface mountable
    Rotation angle
    0°/+355° (with locking mechanism)
    Housing
    Corrosion resistant, marine grade aluminum housing
    Finishing
    Knurled surface in black anodized aluminum and body in chromate conversion pretreatment followed by electrostatic powder coating
    Fasteners
    Stainless steel (AISI 316L)
    Gasket
    EPDM gasket (Shore A 25-30)
    Lens / Reflector
    PMMA lens with high optical efficiency
    Glass / Diffusor
    Tempered safety glass
    Impact protection
    IK07
    Ingress protection
    IP66
    Input voltage
    36 Vdc (Max) 500 mA
    Insulation class
    Class III
    Weight
    3.5kg(0.9m) , 2.5kg(0.6m)
    LED module
    High efficacy COB LED with long time reliability
    Driver
    Remote LED driver
    Through wiring
    Single cable entry
    Operating temperature
    -40...50°C
    Cable
    0.2 m of flexible cable
    Notes
    Please consult factory for combinations of different light distributions. The photometry download contains two separate files, each representing one side of the lighting fixture. To accurately obtain the lighting characteristics for a double-headed layout, both files must be imported into the design software.

    Configurations

    Light distribution
    Spot
    [S] Spot - 8°
    Very narrow
    [VN] Very narrow - 18°
    Narrow
    [N] Narrow - 24°
    Medium narrow
    [MN] Medium narrow - 36°
    Medium
    [M] Medium - 50°
    Delivered lumens flux
    736 lm
    788 lm
    792 lm
    1082 lm
    1178 lm
    1192 lm
    1218 lm
    1220 lm
    1272 lm
    1298 lm
    1328 lm
    1342 lm
    1374 lm
    1402 lm
    1434 lm
    Rated input power
    16 W
    20 W
    Colour temperature
    2700 K CRI 90
    3000 K CRI 90
    4000 K CRI 90

    Variant code

    Light distribution

    Delivered lumens flux

    Rated input power

    Colour temperature

    Control

    Variant code: LB8061.529-EN-S-1000-927
    Light distribution: [S] Spot - 8°
    Delivered lumens flux: 788 lm
    Rated input power: 16 W
    Colour temperature: 2700 K CRI 90
    Control:
    LB8061.529-EN-S-1000-927
    Light distribution
    [S] 8°
    Delivered lumens flux
    788 lm
    Rated input power
    16 W
    Colour temperature
    2700 K CRI 90
    Luminaire efficacy
    49 lm/W
    Lamp
    2 LED
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-S-1000-930
    Light distribution: [S] Spot - 8°
    Delivered lumens flux: 792 lm
    Rated input power: 16 W
    Colour temperature: 3000 K CRI 90
    Control:
    LB8061.529-EN-S-1000-930
    Light distribution
    [S] 8°
    Delivered lumens flux
    792 lm
    Rated input power
    16 W
    Colour temperature
    3000 K CRI 90
    Luminaire efficacy
    50 lm/W
    Lamp
    2 LED
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-S-1000-940
    Light distribution: [S] Spot - 8°
    Delivered lumens flux: 736 lm
    Rated input power: 16 W
    Colour temperature: 4000 K CRI 90
    Control:
    LB8061.529-EN-S-1000-940
    Light distribution
    [S] 8°
    Delivered lumens flux
    736 lm
    Rated input power
    16 W
    Colour temperature
    4000 K CRI 90
    Luminaire efficacy
    46 lm/W
    Lamp
    2 LED
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-VN-500-927
    Light distribution: [VN] Very narrow - 18°
    Delivered lumens flux: 1218 lm
    Rated input power: 20 W
    Colour temperature: 2700 K CRI 90
    Control:
    LB8061.529-EN-VN-500-927
    Light distribution
    [VN] 18°
    Delivered lumens flux
    1218 lm
    Rated input power
    20 W
    Colour temperature
    2700 K CRI 90
    Luminaire efficacy
    61 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-VN-500-930
    Light distribution: [VN] Very narrow - 18°
    Delivered lumens flux: 1342 lm
    Rated input power: 20 W
    Colour temperature: 3000 K CRI 90
    Control:
    LB8061.529-EN-VN-500-930
    Light distribution
    [VN] 18°
    Delivered lumens flux
    1342 lm
    Rated input power
    20 W
    Colour temperature
    3000 K CRI 90
    Luminaire efficacy
    67 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-VN-500-940
    Light distribution: [VN] Very narrow - 18°
    Delivered lumens flux: 1374 lm
    Rated input power: 20 W
    Colour temperature: 4000 K CRI 90
    Control:
    LB8061.529-EN-VN-500-940
    Light distribution
    [VN] 18°
    Delivered lumens flux
    1374 lm
    Rated input power
    20 W
    Colour temperature
    4000 K CRI 90
    Luminaire efficacy
    69 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-N-500-927
    Light distribution: [N] Narrow - 24°
    Delivered lumens flux: 1178 lm
    Rated input power: 20 W
    Colour temperature: 2700 K CRI 90
    Control:
    LB8061.529-EN-N-500-927
    Light distribution
    [N] 24°
    Delivered lumens flux
    1178 lm
    Rated input power
    20 W
    Colour temperature
    2700 K CRI 90
    Luminaire efficacy
    59 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-N-500-930
    Light distribution: [N] Narrow - 24°
    Delivered lumens flux: 1298 lm
    Rated input power: 20 W
    Colour temperature: 3000 K CRI 90
    Control:
    LB8061.529-EN-N-500-930
    Light distribution
    [N] 24°
    Delivered lumens flux
    1298 lm
    Rated input power
    20 W
    Colour temperature
    3000 K CRI 90
    Luminaire efficacy
    65 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-N-500-940
    Light distribution: [N] Narrow - 24°
    Delivered lumens flux: 1328 lm
    Rated input power: 20 W
    Colour temperature: 4000 K CRI 90
    Control:
    LB8061.529-EN-N-500-940
    Light distribution
    [N] 24°
    Delivered lumens flux
    1328 lm
    Rated input power
    20 W
    Colour temperature
    4000 K CRI 90
    Luminaire efficacy
    66 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-MN-500-927
    Light distribution: [MN] Medium narrow - 36°
    Delivered lumens flux: 1082 lm
    Rated input power: 20 W
    Colour temperature: 2700 K CRI 90
    Control:
    LB8061.529-EN-MN-500-927
    Light distribution
    [MN] 36°
    Delivered lumens flux
    1082 lm
    Rated input power
    20 W
    Colour temperature
    2700 K CRI 90
    Luminaire efficacy
    54 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-MN-500-930
    Light distribution: [MN] Medium narrow - 36°
    Delivered lumens flux: 1192 lm
    Rated input power: 20 W
    Colour temperature: 3000 K CRI 90
    Control:
    LB8061.529-EN-MN-500-930
    Light distribution
    [MN] 36°
    Delivered lumens flux
    1192 lm
    Rated input power
    20 W
    Colour temperature
    3000 K CRI 90
    Luminaire efficacy
    60 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-MN-500-940
    Light distribution: [MN] Medium narrow - 36°
    Delivered lumens flux: 1220 lm
    Rated input power: 20 W
    Colour temperature: 4000 K CRI 90
    Control:
    LB8061.529-EN-MN-500-940
    Light distribution
    [MN] 36°
    Delivered lumens flux
    1220 lm
    Rated input power
    20 W
    Colour temperature
    4000 K CRI 90
    Luminaire efficacy
    61 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-M-500-927
    Light distribution: [M] Medium - 50°
    Delivered lumens flux: 1272 lm
    Rated input power: 20 W
    Colour temperature: 2700 K CRI 90
    Control:
    LB8061.529-EN-M-500-927
    Light distribution
    [M] 50°
    Delivered lumens flux
    1272 lm
    Rated input power
    20 W
    Colour temperature
    2700 K CRI 90
    Luminaire efficacy
    64 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-M-500-930
    Light distribution: [M] Medium - 50°
    Delivered lumens flux: 1402 lm
    Rated input power: 20 W
    Colour temperature: 3000 K CRI 90
    Control:
    LB8061.529-EN-M-500-930
    Light distribution
    [M] 50°
    Delivered lumens flux
    1402 lm
    Rated input power
    20 W
    Colour temperature
    3000 K CRI 90
    Luminaire efficacy
    70 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000
    Variant code: LB8061.529-EN-M-500-940
    Light distribution: [M] Medium - 50°
    Delivered lumens flux: 1434 lm
    Rated input power: 20 W
    Colour temperature: 4000 K CRI 90
    Control:
    LB8061.529-EN-M-500-940
    Light distribution
    [M] 50°
    Delivered lumens flux
    1434 lm
    Rated input power
    20 W
    Colour temperature
    4000 K CRI 90
    Luminaire efficacy
    72 lm/W
    Lamp
    2 COB
    MacAdam Ellipse
    3 SDCM
    Lifetime L90B50 (hour)
    >50000

    Accessories (To be ordered separately)

    Extras

    Blue Color Filter

    [BCF]

    Blue Color Filter

    Light output
    Green Color Filter

    [GCF]

    Green Color Filter

    Light output
    Honeycomb

    [HNY]

    Honeycomb

    Light output
    Orange Color Filter

    [OCF]

    Orange Color Filter

    Light output
    Red Color Filter

    [RCF]

    Red Color Filter

    Light output
    Yellow Color Filter

    [YCF]

    Yellow Color Filter

    Light output
    Double powder coating

    [DPC]

    Double powder coating

    Luminaire body options

    Related products

    All flux and power values derived following appropriate IES, CIE and applicable standards.
    Descriptions
    Variants

    Light distribution

    Drive current

    Spot
    [S]

    Spot

    Very narrow
    [VN]

    Very narrow

    Narrow
    [N]

    Narrow

    Medium narrow
    [MN]

    Medium narrow

    Medium
    [M]

    Medium

    Drive current

    500 mA
    [500]

    500 mA

    Colour temperature

    2700 K CRI 90
    [927]

    2700 K CRI 90

    3000 K CRI 90
    [930]

    3000 K CRI 90

    4000 K CRI 90
    [940]

    4000 K CRI 90
