NORMA S

NORMA SNORMA S
NORMA SNORMA S

LB6054.693-EN

CEUKCAIK05IP65Class I
Variants
Light distribution
[SYM-4L] 120°
Delivered lumens flux
199 - 432 lm
Rated input power
6.5 - 10 W
Colour temperature
2700 K CRI 80, 3000 K CRI 80, 4000 K CRI 70, 4000 K CRI 80
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>72, 600
Lifetime L80B50 (hour)
>72, 600
Options
Control
On/Off, DALI
Product colours
BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
Height
1m
Extras
Consult the factory
120-277V 50/60Hz
Luminaire body options
Double powder coating

Technical details



Certificates
CE, UKCA
Mounting
Surface mountable
Housing
Corrosion resistant, extruded, marine grade aluminum housing
Finishing
Chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (AISI 304 / EN 1.4301 grade)
Gasket
Liquid silicone
Lens / Reflector
PMMA lens with high optical efficiency
Glass / Diffusor
Tempered safety glass
Impact protection
IK05
Ingress protection
IP65
Input voltage
220-240V 50/60Hz
Insulation class
Class I
Weight
3.5 kg
LED module
Multi-chip high power LEDs on metal-core PCB
Driver
Integral LED driver
Driver surge protection
1/1 kV
Power factor
> 0.91
Through wiring
Single cable entry
Operating temperature
-25...50°C
Cable
0.5 m of flexible cable

Downloads


Variants


Light distribution
Symmetric, Special effect: 4 lines
[SYM-4L] Symmetric, Special effect: 4 lines - 120°
Delivered lumens flux
199 lm
202 lm
224 lm
247 lm
344 lm
348 lm
391 lm
432 lm
Rated input power
6.5 W
10 W
Colour temperature
2700 K CRI 80
3000 K CRI 80
4000 K CRI 70
4000 K CRI 80

Variant code

Light distribution

Delivered lumens flux

Rated input power

Colour temperature

Control


Variant code: LB6054.693-EN-SYM-4L-350-740
Light distribution: [SYM-4L] Symmetric, Special effect: 4 lines - 120°
Delivered lumens flux: 247 lm
Rated input power: 6.5 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI
LB6054.693-EN-SYM-4L-350-740
Light distribution
[SYM-4L] 120°
Delivered lumens flux
247 lm
Rated input power
6.5 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
49 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>72,600
Lifetime L80B50 (hour)
>72,600
Variant code: LB6054.693-EN-SYM-4L-350-827
Light distribution: [SYM-4L] Symmetric, Special effect: 4 lines - 120°
Delivered lumens flux: 199 lm
Rated input power: 6.5 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI
LB6054.693-EN-SYM-4L-350-827
Light distribution
[SYM-4L] 120°
Delivered lumens flux
199 lm
Rated input power
6.5 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
39 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>72,600
Lifetime L80B50 (hour)
>72,600
Variant code: LB6054.693-EN-SYM-4L-350-830
Light distribution: [SYM-4L] Symmetric, Special effect: 4 lines - 120°
Delivered lumens flux: 202 lm
Rated input power: 6.5 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI
LB6054.693-EN-SYM-4L-350-830
Light distribution
[SYM-4L] 120°
Delivered lumens flux
202 lm
Rated input power
6.5 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
40 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>72,600
Lifetime L80B50 (hour)
>72,600
Variant code: LB6054.693-EN-SYM-4L-350-840
Light distribution: [SYM-4L] Symmetric, Special effect: 4 lines - 120°
Delivered lumens flux: 224 lm
Rated input power: 6.5 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI
LB6054.693-EN-SYM-4L-350-840
Light distribution
[SYM-4L] 120°
Delivered lumens flux
224 lm
Rated input power
6.5 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
44 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>72,600
Lifetime L80B50 (hour)
>72,600
Variant code: LB6054.693-EN-SYM-4L-700-740
Light distribution: [SYM-4L] Symmetric, Special effect: 4 lines - 120°
Delivered lumens flux: 432 lm
Rated input power: 10 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI
LB6054.693-EN-SYM-4L-700-740
Light distribution
[SYM-4L] 120°
Delivered lumens flux
432 lm
Rated input power
10 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
48 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>72,600
Lifetime L80B50 (hour)
>72,600
Variant code: LB6054.693-EN-SYM-4L-700-827
Light distribution: [SYM-4L] Symmetric, Special effect: 4 lines - 120°
Delivered lumens flux: 344 lm
Rated input power: 10 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI
LB6054.693-EN-SYM-4L-700-827
Light distribution
[SYM-4L] 120°
Delivered lumens flux
344 lm
Rated input power
10 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
38 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>72,600
Lifetime L80B50 (hour)
>72,600
Variant code: LB6054.693-EN-SYM-4L-700-830
Light distribution: [SYM-4L] Symmetric, Special effect: 4 lines - 120°
Delivered lumens flux: 348 lm
Rated input power: 10 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI
LB6054.693-EN-SYM-4L-700-830
Light distribution
[SYM-4L] 120°
Delivered lumens flux
348 lm
Rated input power
10 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
38 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>72,600
Lifetime L80B50 (hour)
>72,600
Variant code: LB6054.693-EN-SYM-4L-700-840
Light distribution: [SYM-4L] Symmetric, Special effect: 4 lines - 120°
Delivered lumens flux: 391 lm
Rated input power: 10 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI
LB6054.693-EN-SYM-4L-700-840
Light distribution
[SYM-4L] 120°
Delivered lumens flux
391 lm
Rated input power
10 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
43 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U1-G0
Lifetime L90B50 (hour)
>72,600
Lifetime L80B50 (hour)
>72,600

Accessories (To be ordered separately)


Accessories (To be ordered separately)


Extras


120-277V 50/60Hz

[UNI]

120-277V 50/60Hz

Consult the factory
Double powder coating

[DPC]

Double powder coating

Luminaire body options

All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Symmetric, Special effect: 4 lines
[SYM-4L]

Symmetric, Special effect: 4 lines

Drive current


350 mA
[350]

350 mA

700 mA
[700]

700 mA

Colour temperature


2700 K CRI 80
[827]

2700 K CRI 80

3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

4000 K CRI 80
[840]

4000 K CRI 80

Options

Control

Product colours


On/Off
[ONOFF]

On/Off

DALI
[DALI]

DALI

Product colours


Black
[HM1]

Black

Dark grey
[HM2]

Dark grey

Anthracite grey
[HM3]

Anthracite grey

Light grey
[HM4]

Light grey

White
[HM5]

White

Bronze
[HM6]

Bronze

Custom colour (Please specify RAL code)
[CC]

Custom colour (Please specify RAL code)
