URBAN UNITS Top Module
LP4054.538-EN
Configurations
Light distribution
[SYM] 180°, [ASYM] 360°
Nominal LED lumens flux
4460 - 9600 lm
Nominal LED power
32 W (700 mA) - 64 W (700 mA)
Rated luminaire lumens flux
2534 - 6487 lm
Rated luminaire power
35 - 70 W
Color temperature
4000 K CRI 70, 3000 K CRI 80
BUG rating
B2-U0-G1, B3-U0-G1
Lifetime L90
>60, 000 hours
Lifetime L80
>60, 000 hours
Options
Control
On/Off, 1-10V
Input voltage
220-240V 50/60Hz, 120-277V 50/60Hz
Insulation class
Class I
Product colors
Extras
Finishing options
Double coating
Light output
Constant light output
Housing
Corrosion resistant aluminum housing
Finishing
Electrostatic powder coating
Fasteners
Stainless steel (grade 304)
Gasket
Silicone
Lens / Reflector
PMMA lens with high optical efficiency
Glass / Diffusor
Tempered safety glass
Impact protection
IK08
Ingress protection
IP65
Weight
11 kg
LED module
Multi-chip high power LEDs on metal-core PCB
Driver
Internal LED driver
Driver surge protection
6/6 kV
Power factor
> 0.95
Through wiring
Single cable entry
Operating temperature
-40...50°C
Cable
7 7/8" of flexible cable
Downloads
Configurations
Light distribution
[ASYM] Asymmetric, 180° - 360°
[SYM] Symmetric, 360° - 180°
Nominal LED lumens flux
9600 lm
8920 lm
4460 lm
4800 lm
Nominal LED power
64 W
32 W
Color temperature
4000 K CRI 70
3000 K CRI 80
Configuration code
Configurations name
Optic
Nominal LED lumens flux
Configuration code: LP4054.538-EN-ASYM-700-740
Configurations name: LED 4 - 32W - 700 mA - 4000K CRI 70
Optic: [ASYM] Asymmetric, 180° - 180°
Nominal LED lumens flux: 4800 lm
Nominal LED lumens flux
4800 lm
Nominal LED power
32 W
Rated luminaire lumens flux
3369 lm
Rated luminaire power
35 W
Luminaire efficacy
96 lm/W
Lamp
4 LED
Color Deviation
3 SDCM
BUG rating
B2-U0-G1
Lifetime L90
>60,000 hours
Lifetime L80
>60,000 hours
Configuration code: LP4054.538-EN-ASYM-700-830
Configurations name: LED 4 - 32W - 700 mA - 3000K CRI 80
Optic: [ASYM] Asymmetric, 180° - 360°
Nominal LED lumens flux: 4460 lm
Nominal LED lumens flux
4460 lm
Nominal LED power
32 W
Rated luminaire lumens flux
2534 lm
Rated luminaire power
35 W
Luminaire efficacy
72 lm/W
Lamp
4 LED
Color Deviation
3 SDCM
BUG rating
B3-U0-G1
Lifetime L90
>60,000 hours
Lifetime L80
>60,000 hours
Configuration code: LP4054.538-EN-SYM-700-740
Configurations name: LED 8 - 64W - 700 mA - 4000K CRI 70
Optic: [SYM] Symmetric, 360° - 180°
Nominal LED lumens flux: 9600 lm
Nominal LED lumens flux
9600 lm
Nominal LED power
64 W
Rated luminaire lumens flux
6487 lm
Rated luminaire power
70 W
Luminaire efficacy
93 lm/W
Lamp
8 LED
Color Deviation
3 SDCM
BUG rating
B2-U0-G1
Lifetime L90
>60,000 hours
Lifetime L80
>60,000 hours
Configuration code: LP4054.538-EN-SYM-700-830
Configurations name: LED 8 - 64W - 700 mA - 3000K CRI 80
Optic: [SYM] Symmetric, 360° - 360°
Nominal LED lumens flux: 8920 lm
Nominal LED lumens flux
8920 lm
Nominal LED power
64 W
Rated luminaire lumens flux
5046 lm
Rated luminaire power
70 W
Luminaire efficacy
72 lm/W
Lamp
8 LED
Color Deviation
3 SDCM
BUG rating
B3-U0-G1
Lifetime L90
>60,000 hours
Lifetime L80
>60,000 hours
Descriptions
Configurations
Light distribution
Drive current
[ASYM]
Asymmetric, 180°
[SYM]
Symmetric, 360°
Drive current
[700]
700 mA
Color temperature
[830]
3000 K CRI 80
[740]
4000 K CRI 70
Options
Control
Input voltage
[ONOFF]
On/Off
[1-10V]
1-10V
Input voltage
[EN]
220-240V 50/60Hz
[UNI]
120-277V 50/60Hz
Insulation class
Product colors
[C1]
Class I
Product colors
[HM1]
Black (Textured)
[HM2]
Dark gray (Textured)
[HM3]
Anthracite gray (Textured)
[HM4]
Light gray (Textured)
[HM5]
White (Textured)
[HM6]
Bronze (Textured)
[CC]
Custom Colour (Please specify RAL code)
Extras
Finishing options
Light output
[DC]
Double coating
Light output
[CLO]
Constant light output
