URBAN UNITS Top Module

UPCOMING
URBAN UNITS Top ModuleURBAN UNITS Top Module
URBAN UNITS Top ModuleURBAN UNITS Top Module

LP4054.538-US

Configurations
Light distribution
[SYM] 108.4
Delivered lumens flux
4366 - 7457 lm
Rated input power
48 - 72 W
Color temperature
2200 K CRI 80, 2700 K CRI 80, 3000 K CRI 80, 4000 K CRI 70
Lifetime L90 (hour)
>102 000
Lifetime L80 (hour)
>102 000
Options
Control
On/Off, 0-10V
Product colors
BlackDark grayAnthracite grayLight grayWhiteBronzeCustom color (Please specify RAL code)
Extras
Luminaire body options
Double powder coating

Technical details



Housing
Corrosion resistant, marine grade aluminum housing
Finishing
Chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (AISI 304 / EN 1.4301 grade)
Gasket
Silicone
Lens / Reflector
PMMA lens with high optical efficiency
Glass / Diffusor
UV stable, bio-based polycarbonate diffusor
Impact protection
IK08
Ingress protection
IP65
Input voltage
120-277V 50/60Hz
Insulation class
Class I
Weight
24 lbs
LED module
Multi-chip high power LEDs on metal-core PCB
Driver
Internal LED driver
Driver surge protection
10/6 kV
Power factor
> 0.95
Through wiring
Single power cord entry
Operating temperature
-40...50°C
Power cord
20" of outdoor use rated flexible power cord

Downloads


Configurations


Light distribution
Symmetric
[SYM] Symmetric - 108.4
Delivered lumens flux
4366 lm
4631 lm
4896 lm
5160 lm
6310 lm
6692 lm
7074 lm
7457 lm
Rated input power
48 W
72 W
Color temperature
2200 K CRI 80
2700 K CRI 80
3000 K CRI 80
4000 K CRI 70

Configuration code

Light distribution

Delivered lumens flux

Rated input power

Color temperature

Control


Configuration code: LP4054.538-US-SYM-1050-740
Light distribution: [SYM] Symmetric - 108.4
Delivered lumens flux: 7457 lm
Rated input power: 72 W
Color temperature: 4000 K CRI 70
Control:
Light distribution
[SYM] 108.4
Delivered lumens flux
7457 lm
Rated input power
72 W
Color temperature
4000 K CRI 70
Luminaire efficacy
103 lm/W
Color Deviation
3 SDCM
Lifetime L90 (hour)
>102 000
Lifetime L80 (hour)
>102 000
Configuration code: LP4054.538-US-SYM-1050-822
Light distribution: [SYM] Symmetric - 108.4
Delivered lumens flux: 6310 lm
Rated input power: 72 W
Color temperature: 2200 K CRI 80
Control:
Light distribution
[SYM] 108.4
Delivered lumens flux
6310 lm
Rated input power
72 W
Color temperature
2200 K CRI 80
Luminaire efficacy
87 lm/W
Lifetime L90 (hour)
>102 000
Lifetime L80 (hour)
>102 000
Configuration code: LP4054.538-US-SYM-1050-827
Light distribution: [SYM] Symmetric - 108.4
Delivered lumens flux: 7074 lm
Rated input power: 72 W
Color temperature: 2700 K CRI 80
Control:
Light distribution
[SYM] 108.4
Delivered lumens flux
7074 lm
Rated input power
72 W
Color temperature
2700 K CRI 80
Luminaire efficacy
98 lm/W
Color Deviation
3 SDCM
Lifetime L90 (hour)
>102 000
Lifetime L80 (hour)
>102 000
Configuration code: LP4054.538-US-SYM-1050-830
Light distribution: [SYM] Symmetric - 108.4
Delivered lumens flux: 6692 lm
Rated input power: 72 W
Color temperature: 3000 K CRI 80
Control:
Light distribution
[SYM] 108.4
Delivered lumens flux
6692 lm
Rated input power
72 W
Color temperature
3000 K CRI 80
Luminaire efficacy
98 lm/W
Color Deviation
3 SDCM
Lifetime L90 (hour)
>102 000
Lifetime L80 (hour)
>102 000
Configuration code: LP4054.538-US-SYM-700-740
Light distribution: [SYM] Symmetric - 108.4
Delivered lumens flux: 5160 lm
Rated input power: 48 W
Color temperature: 4000 K CRI 70
Control:
Light distribution
[SYM] 108.4
Delivered lumens flux
5160 lm
Rated input power
48 W
Color temperature
4000 K CRI 70
Luminaire efficacy
103 lm/W
Color Deviation
3 SDCM
Lifetime L90 (hour)
>102 000
Lifetime L80 (hour)
>102 000
Configuration code: LP4054.538-US-SYM-700-822
Light distribution: [SYM] Symmetric - 108.4
Delivered lumens flux: 4366 lm
Rated input power: 48 W
Color temperature: 2200 K CRI 80
Control:
Light distribution
[SYM] 108.4
Delivered lumens flux
4366 lm
Rated input power
48 W
Color temperature
2200 K CRI 80
Luminaire efficacy
92 lm/W
Lifetime L90 (hour)
>102 000
Lifetime L80 (hour)
>102 000
Configuration code: LP4054.538-US-SYM-700-827
Light distribution: [SYM] Symmetric - 108.4
Delivered lumens flux: 4896 lm
Rated input power: 48 W
Color temperature: 2700 K CRI 80
Control:
Light distribution
[SYM] 108.4
Delivered lumens flux
4896 lm
Rated input power
48 W
Color temperature
2700 K CRI 80
Luminaire efficacy
98 lm/W
Color Deviation
3 SDCM
Lifetime L90 (hour)
>102 000
Lifetime L80 (hour)
>102 000
Configuration code: LP4054.538-US-SYM-700-830
Light distribution: [SYM] Symmetric - 108.4
Delivered lumens flux: 4631 lm
Rated input power: 48 W
Color temperature: 3000 K CRI 80
Control:
Light distribution
[SYM] 108.4
Delivered lumens flux
4631 lm
Rated input power
48 W
Color temperature
3000 K CRI 80
Luminaire efficacy
98 lm/W
Color Deviation
3 SDCM
Lifetime L90 (hour)
>102 000
Lifetime L80 (hour)
>102 000

Poles (Included)



All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Configurations

Light distribution

Drive current


Symmetric
[SYM]

Symmetric

Drive current


700 mA
[700]

700 mA

1050 mA
[1050]

1050 mA

Color temperature


2200 K CRI 80
[822]

2200 K CRI 80

2700 K CRI 80
[827]

2700 K CRI 80

3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

Options

Control

Product colors


On/Off
[ONOFF]

On/Off

0-10V
[0-10V]

0-10V

Product colors


Black
[HM1]

Black

Dark gray
[HM2]

Dark gray

Anthracite gray
[HM3]

Anthracite gray

Light gray
[HM4]

Light gray

White
[HM5]

White

Bronze
[HM6]

Bronze

Custom color (Please specify RAL code)
[CC]

Custom color (Please specify RAL code)

Extras

Luminaire body options


Double powder coating
[DPC]

Double powder coating
