T-LIGHT 4 CB Module

T-LIGHT 4 CB ModuleT-LIGHT 4 CB Module
T-LIGHT 4 CB ModuleT-LIGHT 4 CB Module

LT2029.651-EN

CEIK08IP66Class IClass II
Configurations
Light distribution
[T-CB-C] 130° x 85°
Nominal LED lumens flux
9600 lm, 8920 lm
Nominal LED power
64 W (700 mA)
Color temperature
4000 K CRI 70, 3000 K CRI 80
Options
Control
On/Off, DALI, StepDIM
Input voltage
220-240V 50/60Hz
Insulation class
Class I, Class II
Product colors
Black (Textured)Dark gray (Textured)Anthracite gray (Textured)Light gray (Textured)White (Textured)Bronze (Textured)Custom Colour (Please specify RAL code)
Extras
Finishing option
Double coating
Light output
Constant light output

Mounting
Direct tray mountable
Housing
Corrosion resistant aluminum housing
Finishing
Electrostatic powder coating
Fasteners
Stainless steel (grade 304)
Gasket
Silicone
Lens / Reflector
High reflectance aluminium coating, multifaceted micro reflector
Glass / Diffusor
Bio-based, enriched with bisphenol A diffusor
Impact protection
IK08
Ingress protection
IP66
Weight
5.64 kg
LED module
Multi-chip high power LEDs on metal-core PCB
Driver
Thermally-separated internal LED driver
Driver surge protection
10/6 kV
Power factor
> 0.95
Through wiring
Single cable entry
Cable
39 3/8" of halogen-free cable

Downloads


Configurations


Light distribution
Tunnel, Counter beam, Type C
[T-CB-C] Tunnel, Counter beam, Type C - 130° x 85°
Nominal LED lumens flux
9600 lm
8920 lm
Nominal LED power
64 W
Color temperature
4000 K CRI 70
3000 K CRI 80

Configuration code

Configurations name

Optic

Nominal LED lumens flux


Configuration code: LT2029.651-EN-T-CB-C-700-740
Configurations name: MILESTONE 8 - 64W - 700mA - 4000K CRI 70
Optic: [T-CB-C] Tunnel, Counter beam, Type C - 130° x 85°
Nominal LED lumens flux: 9600 lm
Nominal LED lumens flux
9600 lm
Nominal LED power
64 W
Rated luminaire lumens flux
7950 lm
Rated luminaire power
70 W
Luminaire efficacy
114 lm/W
Lamp
8 LED
Color Deviation
3 SDCM
BUG rating
B2-U0-G1
Configuration code: LT2029.651-EN-T-CB-C-700-830
Configurations name: MILESTONE 8 - 64W - 700mA - 3000K CRI 80
Optic: [T-CB-C] Tunnel, Counter beam, Type C - 130° x 85°
Nominal LED lumens flux: 8920 lm
Nominal LED lumens flux
8920 lm
Nominal LED power
64 W
Rated luminaire lumens flux
7394 lm
Rated luminaire power
70 W
Luminaire efficacy
106 lm/W
Lamp
8 LED
Color Deviation
3 SDCM
BUG rating
B2-U0-G1

Descriptions
Configurations

Light distribution

Drive current


Tunnel, Counter beam, Type C
[T-CB-C]

Tunnel, Counter beam, Type C

Drive current


700 mA
[700]

700 mA

Color temperature


3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

Options

Control

Input voltage


On/Off
[ONOFF]

On/Off

DALI
[DALI]

DALI

StepDIM
[STEP]

StepDIM

Input voltage


220-240V 50/60Hz
[EN]

220-240V 50/60Hz

Insulation class

Product colors


Class I
[C1]

Class I

Class II
[C2]

Class II

Product colors


Black (Textured)
[HM1]

Black (Textured)

Dark gray (Textured)
[HM2]

Dark gray (Textured)

Anthracite gray (Textured)
[HM3]

Anthracite gray (Textured)

Light gray (Textured)
[HM4]

Light gray (Textured)

White (Textured)
[HM5]

White (Textured)

Bronze (Textured)
[HM6]

Bronze (Textured)

Custom Colour (Please specify RAL code)
[CC]

Custom Colour (Please specify RAL code)

Extras

Finishing option

Light output


Double coating
[DC]

Double coating

Light output


Constant light output
[CLO]

Constant light output
