    ZEROX Hybrid

    ZEROX HybridZEROX Hybrid
    ZEROX HybridZEROX Hybrid

    LR9005.695-US

    Configurations
    Light distribution
    [N] 26°, [S] 7°
    Delivered lumens flux
    1914 - 3215 lm
    Rated input power
    18 - 28 W
    Color temperature
    2700 K CRI 80, 3000 K CRI 80, 4000 K CRI 70, 4000 K CRI 80
    Lifetime L90 (hour)
    >72, 600
    Lifetime L80 (hour)
    >72, 600
    Options
    Control
    On/Off, 0-10V
    Product colors
    Stainless steel

    Technical details


    Mounting
    Ground recessed mountable
    Housing
    Corrosion resistant stainless steel housing (AISI 316L / EN 1.4571 grade)
    Fasteners
    Stainless steel (AISI 304 / EN 1.4301 grade)
    Gasket
    Silicone
    Lens / Reflector
    High reflectance aluminium coating
    Glass / Diffusor
    Tempered safety glass
    Impact protection
    IK10
    Ingress protection
    IP67
    Input voltage
    120-277V 50/60Hz
    Insulation class
    Class I
    Weight
    15 lbs
    LED module
    Multi-chip high power LEDs on metal-core PCB
    Driver
    Internal LED driver
    Driver surge protection
    10/6 kV
    Power factor
    > 0.95
    Through wiring
    Single power cord entry
    Operating temperature
    -40...50°C
    Power cord
    12" of rubber-sheated power cord

    Downloads

    Configurations

    Light distribution
    Spot - NEMA Type 0
    [S] Spot - NEMA Type 0 - 7°
    Narrow - NEMA Type 2
    [N] Narrow - NEMA Type 2 - 26°
    Delivered lumens flux
    1914 lm
    1947 lm
    2154 lm
    2353 lm
    2585 lm
    2622 lm
    2920 lm
    3215 lm
    Rated input power
    18 W
    28 W
    Color temperature
    2700 K CRI 80
    3000 K CRI 80
    4000 K CRI 70
    4000 K CRI 80

    Configuration code

    Light distribution

    Delivered lumens flux

    Rated input power

    Color temperature

    Control

    Configuration code: LR9005.695-US-S-350-740
    Light distribution: [S] Spot - NEMA Type 0 - 7°
    Delivered lumens flux: 2353 lm
    Rated input power: 18 W
    Color temperature: 4000 K CRI 70
    Control: On/Off, 0-10V
    LR9005.695-US-S-350-740
    Light distribution
    [S] 7°
    Delivered lumens flux
    2353 lm
    Rated input power
    18 W
    Color temperature
    4000 K CRI 70
    Luminaire efficacy
    117 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-S-350-827
    Light distribution: [S] Spot - NEMA Type 0 - 7°
    Delivered lumens flux: 1914 lm
    Rated input power: 18 W
    Color temperature: 2700 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-S-350-827
    Light distribution
    [S] 7°
    Delivered lumens flux
    1914 lm
    Rated input power
    18 W
    Color temperature
    2700 K CRI 80
    Luminaire efficacy
    95 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-S-350-830
    Light distribution: [S] Spot - NEMA Type 0 - 7°
    Delivered lumens flux: 1947 lm
    Rated input power: 18 W
    Color temperature: 3000 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-S-350-830
    Light distribution
    [S] 7°
    Delivered lumens flux
    1947 lm
    Rated input power
    18 W
    Color temperature
    3000 K CRI 80
    Luminaire efficacy
    97 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-S-350-840
    Light distribution: [S] Spot - NEMA Type 0 - 7°
    Delivered lumens flux: 2154 lm
    Rated input power: 18 W
    Color temperature: 4000 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-S-350-840
    Light distribution
    [S] 7°
    Delivered lumens flux
    2154 lm
    Rated input power
    18 W
    Color temperature
    4000 K CRI 80
    Luminaire efficacy
    107 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-S-500-740
    Light distribution: [S] Spot - NEMA Type 0 - 7°
    Delivered lumens flux: 3215 lm
    Rated input power: 28 W
    Color temperature: 4000 K CRI 70
    Control: On/Off, 0-10V
    LR9005.695-US-S-500-740
    Light distribution
    [S] 7°
    Delivered lumens flux
    3215 lm
    Rated input power
    28 W
    Color temperature
    4000 K CRI 70
    Luminaire efficacy
    114 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-S-500-827
    Light distribution: [S] Spot - NEMA Type 0 - 7°
    Delivered lumens flux: 2585 lm
    Rated input power: 28 W
    Color temperature: 2700 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-S-500-827
    Light distribution
    [S] 7°
    Delivered lumens flux
    2585 lm
    Rated input power
    28 W
    Color temperature
    2700 K CRI 80
    Luminaire efficacy
    92 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-S-500-830
    Light distribution: [S] Spot - NEMA Type 0 - 7°
    Delivered lumens flux: 2622 lm
    Rated input power: 28 W
    Color temperature: 3000 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-S-500-830
    Light distribution
    [S] 7°
    Delivered lumens flux
    2622 lm
    Rated input power
    28 W
    Color temperature
    3000 K CRI 80
    Luminaire efficacy
    93 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-S-500-840
    Light distribution: [S] Spot - NEMA Type 0 - 7°
    Delivered lumens flux: 2920 lm
    Rated input power: 28 W
    Color temperature: 4000 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-S-500-840
    Light distribution
    [S] 7°
    Delivered lumens flux
    2920 lm
    Rated input power
    28 W
    Color temperature
    4000 K CRI 80
    Luminaire efficacy
    104 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-N-350-740
    Light distribution: [N] Narrow - NEMA Type 2 - 26°
    Delivered lumens flux: 2353 lm
    Rated input power: 18 W
    Color temperature: 4000 K CRI 70
    Control: On/Off, 0-10V
    LR9005.695-US-N-350-740
    Light distribution
    [N] 26°
    Delivered lumens flux
    2353 lm
    Rated input power
    18 W
    Color temperature
    4000 K CRI 70
    Luminaire efficacy
    117 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-N-350-827
    Light distribution: [N] Narrow - NEMA Type 2 - 26°
    Delivered lumens flux: 1914 lm
    Rated input power: 18 W
    Color temperature: 2700 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-N-350-827
    Light distribution
    [N] 26°
    Delivered lumens flux
    1914 lm
    Rated input power
    18 W
    Color temperature
    2700 K CRI 80
    Luminaire efficacy
    95 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-N-350-830
    Light distribution: [N] Narrow - NEMA Type 2 - 26°
    Delivered lumens flux: 1947 lm
    Rated input power: 18 W
    Color temperature: 3000 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-N-350-830
    Light distribution
    [N] 26°
    Delivered lumens flux
    1947 lm
    Rated input power
    18 W
    Color temperature
    3000 K CRI 80
    Luminaire efficacy
    97 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-N-350-840
    Light distribution: [N] Narrow - NEMA Type 2 - 26°
    Delivered lumens flux: 2154 lm
    Rated input power: 18 W
    Color temperature: 4000 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-N-350-840
    Light distribution
    [N] 26°
    Delivered lumens flux
    2154 lm
    Rated input power
    18 W
    Color temperature
    4000 K CRI 80
    Luminaire efficacy
    107 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-N-500-740
    Light distribution: [N] Narrow - NEMA Type 2 - 26°
    Delivered lumens flux: 3215 lm
    Rated input power: 28 W
    Color temperature: 4000 K CRI 70
    Control: On/Off, 0-10V
    LR9005.695-US-N-500-740
    Light distribution
    [N] 26°
    Delivered lumens flux
    3215 lm
    Rated input power
    28 W
    Color temperature
    4000 K CRI 70
    Luminaire efficacy
    114 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-N-500-827
    Light distribution: [N] Narrow - NEMA Type 2 - 26°
    Delivered lumens flux: 2585 lm
    Rated input power: 28 W
    Color temperature: 2700 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-N-500-827
    Light distribution
    [N] 26°
    Delivered lumens flux
    2585 lm
    Rated input power
    28 W
    Color temperature
    2700 K CRI 80
    Luminaire efficacy
    92 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-N-500-830
    Light distribution: [N] Narrow - NEMA Type 2 - 26°
    Delivered lumens flux: 2622 lm
    Rated input power: 28 W
    Color temperature: 3000 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-N-500-830
    Light distribution
    [N] 26°
    Delivered lumens flux
    2622 lm
    Rated input power
    28 W
    Color temperature
    3000 K CRI 80
    Luminaire efficacy
    93 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600
    Configuration code: LR9005.695-US-N-500-840
    Light distribution: [N] Narrow - NEMA Type 2 - 26°
    Delivered lumens flux: 2920 lm
    Rated input power: 28 W
    Color temperature: 4000 K CRI 80
    Control: On/Off, 0-10V
    LR9005.695-US-N-500-840
    Light distribution
    [N] 26°
    Delivered lumens flux
    2920 lm
    Rated input power
    28 W
    Color temperature
    4000 K CRI 80
    Luminaire efficacy
    104 lm/W
    Lamp
    4 LED
    Color Deviation
    5 SDCM
    Lifetime L90 (hour)
    >72,600
    Lifetime L80 (hour)
    >72,600

    Accessories (Included)

    Accessories (To be ordered separately)

    Accessories (To be ordered separately)

    All flux and power values derived following appropriate IES, CIE and applicable standards.
    Descriptions
    Configurations

    Light distribution

    Drive current

    Spot - NEMA Type 0
    [S]

    Spot - NEMA Type 0

    Narrow - NEMA Type 2
    [N]

    Narrow - NEMA Type 2

    Drive current

    350 mA
    [350]

    350 mA

    500 mA
    [500]

    500 mA

    Color temperature

    2700 K CRI 80
    [827]

    2700 K CRI 80

    3000 K CRI 80
    [830]

    3000 K CRI 80

    4000 K CRI 70
    [740]

    4000 K CRI 70

    4000 K CRI 80
    [840]

    4000 K CRI 80

    Options

    Control

    Product colors

    On/Off
    [ONOFF]

    On/Off

    0-10V
    [0-10V]

    0-10V

    Product colors

    Stainless steel
    [SS]

    Stainless steel
