PUNTO L

PUNTO LPUNTO L
PUNTO LPUNTO L

LF8019.698-US

ULIK08IP65Class I
Configurations
Light distribution
[N] 26°, [S] 7°
Nominal LED lumens flux
8575 lm, 7980 lm
Nominal LED power
56 W (700 mA)
Color temperature
4000 K CRI 70, 3000 K CRI 80
Options
Control
On/Off, 1-10V, DALI
Input voltage
120-277V 50/60Hz
Insulation class
Class I
Product colors
Black (Textured)Dark gray (Textured)Anthracite gray (Textured)Light gray (Textured)White (Textured)Bronze (Textured)Custom Colour (Please specify RAL code)
Extras
Finishing option
Double coating

Mounting
Standard bracket mount, spike mount or special driver housing mount
Tilt angle
-15°/+15°
Housing
Corrosion resistant die-cast aluminum housing
Finishing
Electrostatic powder coating
Fasteners
Stainless steel (grade 304)
Gasket
Silicone rubber
Lens / Reflector
High reflectance aluminium coating
Glass / Diffusor
Tempered safety glass
Impact protection
IK08
Ingress protection
IP65
Weight
14.4 lb
LED module
Multi-chip high power LEDs on metal-core PCB
Driver
Thermally-separated internal LED driver
Driver surge protection
1/1 kV
Power factor
> 0.99
Through wiring
Single cable entry
Cable
0.4 m of flexible cable

Downloads


Configurations


Light distribution
Narrow - NEMA Type 2
[N] Narrow - NEMA Type 2 - 26°
Spot - NEMA Type 0
[S] Spot - NEMA Type 0 - 7°
Nominal LED lumens flux
8575 lm
7980 lm
Nominal LED power
56 W
Color temperature
4000 K CRI 70
3000 K CRI 80

Configuration code

Configurations name

Optic

Nominal LED lumens flux


Configuration code: LF8019.698-US-N-700-740
Configurations name: HYBRID 7 - 56W - 700mA - 4000K CRI 70
Optic: [N] Narrow - NEMA Type 2 - 26°
Nominal LED lumens flux: 8575 lm
LF8019.698-US-N-700-740
Nominal LED lumens flux
8575 lm
Nominal LED power
56 W
Rated luminaire lumens flux
7105 lm
Rated luminaire power
58 W
Luminaire efficacy
123 lm/W
Lamp
7 LED
Color Deviation
5 SDCM
Configuration code: LF8019.698-US-N-700-830
Configurations name: HYBRID 7 - 56W - 700mA - 3000K CRI 80
Optic: [N] Narrow - NEMA Type 2 - 26°
Nominal LED lumens flux: 7980 lm
LF8019.698-US-N-700-830
Nominal LED lumens flux
7980 lm
Nominal LED power
56 W
Rated luminaire lumens flux
6608 lm
Rated luminaire power
58 W
Luminaire efficacy
114 lm/W
Lamp
7 LED
Color Deviation
5 SDCM
Configuration code: LF8019.698-US-S-700-740
Configurations name: HYBRID 7 - 56W - 700mA - 4000K CRI 70
Optic: [S] Spot - NEMA Type 0 - 7°
Nominal LED lumens flux: 8575 lm
LF8019.698-US-S-700-740
Nominal LED lumens flux
8575 lm
Nominal LED power
56 W
Rated luminaire lumens flux
7105 lm
Rated luminaire power
58 W
Luminaire efficacy
123 lm/W
Lamp
7 LED
Color Deviation
5 SDCM
Configuration code: LF8019.698-US-S-700-830
Configurations name: HYBRID 7 - 56W - 700mA - 3000K CRI 80
Optic: [S] Spot - NEMA Type 0 - 7°
Nominal LED lumens flux: 7980 lm
LF8019.698-US-S-700-830
Nominal LED lumens flux
7980 lm
Nominal LED power
56 W
Rated luminaire lumens flux
6608 lm
Rated luminaire power
58 W
Luminaire efficacy
114 lm/W
Lamp
7 LED
Color Deviation
5 SDCM

Accessories (To be ordered separately)


Accessories (To be ordered separately)



Descriptions
Configurations

Light distribution

Drive current


Narrow - NEMA Type 2
[N]

Narrow - NEMA Type 2

Spot - NEMA Type 0
[S]

Spot - NEMA Type 0

Drive current


700 mA
[700]

700 mA

Color temperature


3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

Options

Control

Input voltage


On/Off
[ONOFF]

On/Off

1-10V
[DIM]

1-10V

DALI
[DALI]

DALI

Input voltage


120-277V 50/60Hz
[UNI]

120-277V 50/60Hz

Insulation class

Product colors


Class I
[C1]

Class I

Product colors


Black (Textured)
[HM1]

Black (Textured)

Dark gray (Textured)
[HM2]

Dark gray (Textured)

Anthracite gray (Textured)
[HM3]

Anthracite gray (Textured)

Light gray (Textured)
[HM4]

Light gray (Textured)

White (Textured)
[HM5]

White (Textured)

Bronze (Textured)
[HM6]

Bronze (Textured)

Custom Colour (Please specify RAL code)
[CC]

Custom Colour (Please specify RAL code)

Extras

Finishing option


Double coating
[DC]

Double coating
