    DOGO Ex Side

    NEW
    QUICK-SHIP
    DOGO Ex SideDOGO Ex SideDOGO Ex SideDOGO Ex Side
    DOGO Ex SideDOGO Ex SideDOGO Ex SideDOGO Ex Side

    LW7035.585-EN

    CEUKCAIK08IP65Class I
    Variants
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    496 - 1170 lm
    Rated input power
    5 - 10 W
    Colour temperature
    2200 K CRI 80, 2700 K CRI 80, 3000 K CRI 80, 4000 K CRI 70, 4000 K CRI 80
    BUG rating
    B0-U0-G0, B1-U0-G1
    Lifetime L90B50 (hour)
    >42, 000
    Lifetime L80B50 (hour)
    >42, 000
    Options
    Control
    On/Off, DALI
    Product colours
    BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
    Extras
    Consult the factory
    Emergency kit, Motion sensor
    Luminaire body options
    Double powder coating

    Technical details


    Certificates
    CE, UKCA
    Mounting
    Surface or wall mountable with angle setting mechanism
    Tilt angle
    +135°/0°
    Housing
    Corrosion resistant, die-cast, marine grade aluminum housing
    Finishing
    Chromate conversion pretreatment followed by electrostatic powder coating
    Fasteners
    Stainless steel (AISI 304 / EN 1.4301 grade)
    Gasket
    Silicone
    Lens / Reflector
    High reflectance aluminium coating, multifaceted micro reflector
    Glass / Diffusor
    Tempered safety glass
    Impact protection
    IK08
    Ingress protection
    IP65
    Input voltage
    220-240V 50/60Hz
    Insulation class
    Class I
    Wind catching area (EPA)
    N/A
    Weight
    5.1 kg
    LED module
    High power LEDs on metal-core PCB
    Driver
    Internal LED driver
    Driver surge protection
    1/1 kV
    Power factor
    > 0.90
    Through wiring
    Single cable entry
    Operating temperature
    -40...50°C
    Cable
    0.2 m of flexible cable
    Notes
    QUICK SHIP: Some variants will be delivered faster. Please consult the factory.

    Downloads

    Variants

    Light distribution
    Special linear, Side throw
    [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux
    496 lm
    499 lm
    554 lm
    585 lm
    803 lm
    998 lm
    1030 lm
    1108 lm
    1170 lm
    Rated input power
    5 W
    10 W
    Colour temperature
    2200 K CRI 80
    2700 K CRI 80
    3000 K CRI 80
    4000 K CRI 70
    4000 K CRI 80

    Variant code

    Light distribution

    Delivered lumens flux

    Rated input power

    Colour temperature

    Control

    Variant code: LW7035.585-EN-SLSW-350-740
    Light distribution: [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux: 585 lm
    Rated input power: 5 W
    Colour temperature: 4000 K CRI 70
    Control: On/Off
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    585 lm
    Rated input power
    5 W
    Colour temperature
    4000 K CRI 70
    Luminaire efficacy
    109 lm/W
    Lamp
    2 LED
    BUG rating
    B0-U0-G0
    Lifetime L90B50 (hour)
    >42,000
    Lifetime L80B50 (hour)
    >42,000
    Variant code: LW7035.585-EN-SLSW-350-822
    Light distribution: [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux: 585 lm
    Rated input power: 5 W
    Colour temperature: 4000 K CRI 70
    Control: On/Off
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    585 lm
    Rated input power
    5 W
    Colour temperature
    4000 K CRI 70
    Luminaire efficacy
    109 lm/W
    Lamp
    2 LED
    BUG rating
    B0-U0-G0
    Lifetime L90B50 (hour)
    >42,000
    Lifetime L80B50 (hour)
    >42,000
    Variant code: LW7035.585-EN-SLSW-350-827
    Light distribution: [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux: 499 lm
    Rated input power: 5 W
    Colour temperature: 2700 K CRI 80
    Control: On/Off
    LW7035.585-EN-SLSW-350-827
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    499 lm
    Rated input power
    5 W
    Colour temperature
    2700 K CRI 80
    Luminaire efficacy
    99 lm/W
    Lamp
    2 LED
    BUG rating
    B0-U0-G0
    Lifetime L90B50 (hour)
    >42,000
    Lifetime L80B50 (hour)
    >42,000
    Variant code: LW7035.585-EN-SLSW-350-830
    Light distribution: [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux: 496 lm
    Rated input power: 5 W
    Colour temperature: 3000 K CRI 80
    Control: On/Off
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    496 lm
    Rated input power
    5 W
    Colour temperature
    3000 K CRI 80
    Luminaire efficacy
    99 lm/W
    Lamp
    2 LED
    BUG rating
    B0-U0-G0
    Lifetime L90B50 (hour)
    >42,000
    Lifetime L80B50 (hour)
    >42,000
    Variant code: LW7035.585-EN-SLSW-350-840
    Light distribution: [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux: 554 lm
    Rated input power: 5 W
    Colour temperature: 4000 K CRI 80
    Control: On/Off
    LW7035.585-EN-SLSW-350-840
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    554 lm
    Rated input power
    5 W
    Colour temperature
    4000 K CRI 80
    Luminaire efficacy
    110 lm/W
    Lamp
    2 LED
    BUG rating
    B0-U0-G0
    Lifetime L90B50 (hour)
    >42,000
    Lifetime L80B50 (hour)
    >42,000
    Variant code: LW7035.585-EN-SLSW-700-740
    Light distribution: [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux: 1170 lm
    Rated input power: 10 W
    Colour temperature: 4000 K CRI 70
    Control: On/Off
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    1170 lm
    Rated input power
    10 W
    Colour temperature
    4000 K CRI 70
    Luminaire efficacy
    117 lm/W
    Lamp
    2 LED
    BUG rating
    B1-U0-G1
    Lifetime L90B50 (hour)
    >42,000
    Lifetime L80B50 (hour)
    >42,000
    Variant code: LW7035.585-EN-SLSW-700-822
    Light distribution: [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux: 803 lm
    Rated input power: 10 W
    Colour temperature: 2200 K CRI 80
    Control: On/Off
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    803 lm
    Rated input power
    10 W
    Colour temperature
    2200 K CRI 80
    Luminaire efficacy
    80 lm/W
    Lamp
    2 LED
    BUG rating
    B1-U0-G1
    Lifetime L90B50 (hour)
    >42,000
    Lifetime L80B50 (hour)
    >42,000
    Variant code: LW7035.585-EN-SLSW-700-827
    Light distribution: [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux: 998 lm
    Rated input power: 10 W
    Colour temperature: 2700 K CRI 80
    Control: On/Off
    LW7035.585-EN-SLSW-700-827
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    998 lm
    Rated input power
    10 W
    Colour temperature
    2700 K CRI 80
    Luminaire efficacy
    99 lm/W
    Lamp
    2 LED
    BUG rating
    B1-U0-G1
    Lifetime L90B50 (hour)
    >42,000
    Lifetime L80B50 (hour)
    >42,000
    Variant code: LW7035.585-EN-SLSW-700-830
    Light distribution: [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux: 1030 lm
    Rated input power: 10 W
    Colour temperature: 3000 K CRI 80
    Control: On/Off
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    1030 lm
    Rated input power
    10 W
    Colour temperature
    3000 K CRI 80
    Luminaire efficacy
    103 lm/W
    Lamp
    2 LED
    BUG rating
    B1-U0-G1
    Lifetime L90B50 (hour)
    >42,000
    Lifetime L80B50 (hour)
    >42,000
    Variant code: LW7035.585-EN-SLSW-700-840
    Light distribution: [SLSW] Special linear, Side throw - 154x55°
    Delivered lumens flux: 1108 lm
    Rated input power: 10 W
    Colour temperature: 4000 K CRI 80
    Control: On/Off
    LW7035.585-EN-SLSW-700-840
    Light distribution
    [SLSW] 154x55°
    Delivered lumens flux
    1108 lm
    Rated input power
    10 W
    Colour temperature
    4000 K CRI 80
    Luminaire efficacy
    110 lm/W
    Lamp
    2 LED
    BUG rating
    B1-U0-G1
    Lifetime L90B50 (hour)
    >42,000
    Lifetime L80B50 (hour)
    >42,000

    Accessories (To be ordered separately)

    Accessories (To be ordered separately)

    All flux and power values derived following appropriate IES, CIE and applicable standards.
    Descriptions
    Variants

    Light distribution

    Drive current

    Special linear, Side throw
    [SLSW]

    Special linear, Side throw

    Drive current

    350 mA
    [350]

    350 mA

    700 mA
    [700]

    700 mA

    Colour temperature

    2200 K CRI 80
    [822]

    2200 K CRI 80

    2700 K CRI 80
    [827]

    2700 K CRI 80

    3000 K CRI 80
    [830]

    3000 K CRI 80

    4000 K CRI 70
    [740]

    4000 K CRI 70

    4000 K CRI 80
    [840]

    4000 K CRI 80

    Options

    Control

    Product colours

    On/Off
    [ONOFF]

    On/Off

    DALI
    [DALI]

    DALI

    Product colours

    Black
    [HM1]

    Black

    Dark grey
    [HM2]

    Dark grey

    Anthracite grey
    [HM3]

    Anthracite grey

    Light grey
    [HM4]

    Light grey

    White
    [HM5]

    White

    Bronze
    [HM6]

    Bronze

    Custom colour (Please specify RAL code)
    [CC]

    Custom colour (Please specify RAL code)

    Extras

    Consult the factory

    Luminaire body options

    Emergency kit
    [EK]

    Emergency kit

    Motion sensor
    [MS]

    Motion sensor

    Luminaire body options

    Double powder coating
    [DPC]

    Double powder coating
