GOLEDO-IN 32 LED

GOLEDO-IN 32 LED
GOLEDO-IN 32 LED

LW2037.761-EN

CEENECENEC+IK08IP66Class IClass II
Variants
Light distribution
[N] 25°, [M] 50°
Nominal LED lumens flux
10496 - 11008 lm
Nominal LED power
64 W (700 mA)
Rated luminaire lumens flux
8567 - 9175 lm
Rated luminaire power
70 W
Colour temperature
4000 K CRI 70, 3000 K CRI 80
BUG rating
B4-U0-G1
Options
Control
On/Off, DALI, AstroDIM, StepDIM
Input voltage
220-240V 50/60Hz, 120-277V 50/60Hz
Insulation class
Class I, Class II
Product colours
Black (Textured)Dark grey (Textured)Anthracite grey (Textured)Light grey (Textured)White (Textured)Bronze (Textured)Custom Colour (Please specify RAL code)
Extras
Finishing option
Double coating
Light output
Constant light output

Mounting
Standard strap connection. Sliding mounting bracket is optional through extra
Housing
Corrosion resistant die-cast aluminum housing
Finishing
Electrostatic powder coating
Fasteners
Stainless steel (grade 304)
Gasket
Silicone
Lens / Reflector
PMMA lens with high optical efficiency
Glass / Diffusor
Tempered safety glass
Impact protection
IK08
Ingress protection
IP66
Weight
8.86 kg
LED module
High power LEDs on metal-core PCB
Driver
Thermally-separated internal LED driver
Driver surge protection
10/6 kV
Power factor
> 0.95
Through wiring
Single cable entry
Cable
1 m of halogen-free cable

Downloads


Variants


Light distribution
Narrow
[N] Narrow - 25°
Medium
[M] Medium - 50°
Nominal LED lumens flux
11008 lm
10496 lm
Nominal LED power
64 W
Colour temperature
4000 K CRI 70
3000 K CRI 80

Variant code

Variant name

Optic

Nominal LED lumens flux


Variant code: LW2037.761-EN-M-700-740
Variant name: LED 32 - 64W - 700mA - 4000K CRI 70
Optic: [M] Medium - 50°
Nominal LED lumens flux: 11008 lm
LW2037.761-EN-M-700-740
Nominal LED lumens flux
11008 lm
Nominal LED power
64 W
Rated luminaire lumens flux
8982 lm
Rated luminaire power
70 W
Luminaire efficacy
128 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B4-U0-G1
Variant code: LW2037.761-EN-M-700-830
Variant name: LED 32 - 64W - 700mA - 3000K CRI 80
Optic: [M] Medium - 50°
Nominal LED lumens flux: 10496 lm
LW2037.761-EN-M-700-830
Nominal LED lumens flux
10496 lm
Nominal LED power
64 W
Rated luminaire lumens flux
8567 lm
Rated luminaire power
70 W
Luminaire efficacy
123 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B4-U0-G1
Variant code: LW2037.761-EN-N-700-740
Variant name: LED 32 - 64W - 700mA - 4000K CRI 70
Optic: [N] Narrow - 25°
Nominal LED lumens flux: 11008 lm
LW2037.761-EN-N-700-740
Nominal LED lumens flux
11008 lm
Nominal LED power
64 W
Rated luminaire lumens flux
9175 lm
Rated luminaire power
70 W
Luminaire efficacy
131 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B4-U0-G1
Variant code: LW2037.761-EN-N-700-830
Variant name: LED 32 - 64W - 700mA - 3000K CRI 80
Optic: [N] Narrow - 25°
Nominal LED lumens flux: 10496 lm
LW2037.761-EN-N-700-830
Nominal LED lumens flux
10496 lm
Nominal LED power
64 W
Rated luminaire lumens flux
8713 lm
Rated luminaire power
70 W
Luminaire efficacy
125 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B4-U0-G1
All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Narrow
[N]

Narrow

Medium
[M]

Medium

Drive current


700 mA
[700]

700 mA

Colour temperature


3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

Options

Control

Input voltage


On/Off
[ONOFF]

On/Off

DALI
[DALI]

DALI

AstroDIM
[ASTRO]

AstroDIM

StepDIM
[STEP]

StepDIM

Input voltage


220-240V 50/60Hz
[EN]

220-240V 50/60Hz

120-277V 50/60Hz
[UNI]

120-277V 50/60Hz

Insulation class

Product colours


Class I
[C1]

Class I

Class II
[C2]

Class II

Product colours


Black (Textured)
[HM1]

Black (Textured)

Dark grey (Textured)
[HM2]

Dark grey (Textured)

Anthracite grey (Textured)
[HM3]

Anthracite grey (Textured)

Light grey (Textured)
[HM4]

Light grey (Textured)

White (Textured)
[HM5]

White (Textured)

Bronze (Textured)
[HM6]

Bronze (Textured)

Custom Colour (Please specify RAL code)
[CC]

Custom Colour (Please specify RAL code)

Extras

Finishing option

Light output


Double coating
[DC]

Double coating

Light output


Constant light output
[CLO]

Constant light output
