DOMINO AFX 1 Module Duo

NEW
DOMINO AFX 1 Module DuoDOMINO AFX 1 Module Duo
DOMINO AFX 1 Module DuoDOMINO AFX 1 Module Duo

LP4091.861-EN

CEUKCAIK08IP66Class I
Variants
Light distribution
[P4] 20x78°, [T1] 111x48°, [T2] 133x48°, [T3] 143x63°, [T4] 117x64°, [T5] 117°
Delivered lumens flux
2985 - 9085 lm
Rated input power
36 - 70 W
Colour temperature
2200 K CRI 80, 2700 K CRI 80, 3000 K CRI 80, 4000 K CRI 70, 4000 K CRI 80
BUG rating
B1-U0-G0, B0-U0-G0, B1-U0-G1, B2-U0-G1, B2-U0-G0
Lifetime L90B10 (hour)
>102, 000
Lifetime L90B50 (hour)
>102, 000
Options
Control
On/Off, DALI, AutoDIM, StepDIM
Product colours
BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
Height
4m, 5m, 6m
Extras
Light output
Backlight Shield, Constant light output, Prismatic Glass
Consult the factory
Motion sensor, 120-277V 50/60Hz
Luminaire body options
Double powder coating

Technical details



Certificates
CE, UKCA, DarkSky Friendly
Mounting
Surface mountable
Housing
Corrosion resistant, marine grade aluminum housing
Finishing
Chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (AISI 304 / EN 1.4301 grade)
Gasket
Liquid silicone
Lens / Reflector
PMMA lens with high optical efficiency
Glass / Diffusor
Tempered safety glass
Impact protection
IK08
Ingress protection
IP66
Input voltage
220-240V 50/60Hz
Insulation class
Class I
Weight
50.35 kg (4 m), 110.77 kg (5 m), 115.87 kg (6 m)
LED module
High power LEDs on metal-core PCB
Driver
Integral LED driver
Driver surge protection
10/6 kV
Power factor
> 0.95
Through wiring
Single cable entry
Operating temperature
-40...50°C
Cable
0.5 m of flexible cable
Pole detail
Poles are supplied with flange plate. Flange cover and anchorage can be ordered separately. Embedded base is optional
Notes
3000K CCT or warmer must be selected to be DarkSky International certified. Prismatic Glass enhances visual comfort and alters light distribution, reducing delivered lumens by approximately 10%. For specifications with Prismatic Glass and photometry files, please contact the factory. The photometry download contains two separate files, each representing one side of the lighting fixture. To accurately obtain the lighting characteristics for a double-headed layout, both files must be imported into the design software.

Downloads


Variants


Light distribution
Type I, Asymmetric, Side throw
[T1] Type I, Asymmetric, Side throw - 111x48°
Type II, Asymmetric, Side throw
[T2] Type II, Asymmetric, Side throw - 133x48°
Type III, Asymmetric, Side throw
[T3] Type III, Asymmetric, Side throw - 143x63°
Type IV, Asymmetric, Forward throw
[T4] Type IV, Asymmetric, Forward throw - 117x64°
Type V, Symmetric
[T5] Type V, Symmetric - 117°
Special pedestrian road distribution-right side traffic
[P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux
2985 lm
3125 lm
3235 lm
3265 lm
3285 lm
3340 lm
3785 lm
3955 lm
3965 lm
4115 lm
4165 lm
4235 lm
4315 lm
4355 lm
4510 lm
4520 lm
4555 lm
4560 lm
4585 lm
4590 lm
4665 lm
4690 lm
4830 lm
5370 lm
5390 lm
5605 lm
5620 lm
5790 lm
5830 lm
5870 lm
5875 lm
5880 lm
5910 lm
5915 lm
5940 lm
6015 lm
6315 lm
6565 lm
6785 lm
6830 lm
6880 lm
6920 lm
6980 lm
7255 lm
7500 lm
7545 lm
7645 lm
8240 lm
8705 lm
8925 lm
8940 lm
9025 lm
9085 lm
Rated input power
36 W
50 W
70 W
Colour temperature
2200 K CRI 80
2700 K CRI 80
3000 K CRI 80
4000 K CRI 70
4000 K CRI 80

Variant code

Light distribution

Delivered lumens flux

Rated input power

Colour temperature

Control


Variant code: LP4091.861-EN-T1-350-740
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 4830 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-350-740
Light distribution
[T1] 111x48°
Delivered lumens flux
4830 lm
Rated input power
36 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
142 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-350-822
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 3340 lm
Rated input power: 36 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T1] 111x48°
Delivered lumens flux
3340 lm
Rated input power
36 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
93 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-350-827
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 4235 lm
Rated input power: 36 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-350-827
Light distribution
[T1] 111x48°
Delivered lumens flux
4235 lm
Rated input power
36 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
125 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-350-830
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 4235 lm
Rated input power: 36 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-350-830
Light distribution
[T1] 111x48°
Delivered lumens flux
4235 lm
Rated input power
36 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
125 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-350-840
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 4235 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-350-840
Light distribution
[T1] 111x48°
Delivered lumens flux
4235 lm
Rated input power
36 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
125 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-500-740
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 6785 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-500-740
Light distribution
[T1] 111x48°
Delivered lumens flux
6785 lm
Rated input power
50 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
141 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-500-822
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 4665 lm
Rated input power: 50 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T1] 111x48°
Delivered lumens flux
4665 lm
Rated input power
50 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
93 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-500-827
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 5790 lm
Rated input power: 50 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-500-827
Light distribution
[T1] 111x48°
Delivered lumens flux
5790 lm
Rated input power
50 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
120 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-500-830
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 5790 lm
Rated input power: 50 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-500-830
Light distribution
[T1] 111x48°
Delivered lumens flux
5790 lm
Rated input power
50 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
120 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-500-840
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 5790 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-500-840
Light distribution
[T1] 111x48°
Delivered lumens flux
5790 lm
Rated input power
50 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
120 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-700-740
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 8925 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-700-740
Light distribution
[T1] 111x48°
Delivered lumens flux
8925 lm
Rated input power
70 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
133 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-700-822
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 6015 lm
Rated input power: 70 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T1] 111x48°
Delivered lumens flux
6015 lm
Rated input power
70 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
86 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-700-827
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 7500 lm
Rated input power: 70 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-700-827
Light distribution
[T1] 111x48°
Delivered lumens flux
7500 lm
Rated input power
70 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
111 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-700-830
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 7500 lm
Rated input power: 70 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-700-830
Light distribution
[T1] 111x48°
Delivered lumens flux
7500 lm
Rated input power
70 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
111 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T1-700-840
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 7500 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T1-700-840
Light distribution
[T1] 111x48°
Delivered lumens flux
7500 lm
Rated input power
70 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
111 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-350-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 4510 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-350-740
Light distribution
[T2] 133x48°
Delivered lumens flux
4510 lm
Rated input power
36 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
133 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-350-822
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3265 lm
Rated input power: 36 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T2] 133x48°
Delivered lumens flux
3265 lm
Rated input power
36 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
91 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-350-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3955 lm
Rated input power: 36 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-350-827
Light distribution
[T2] 133x48°
Delivered lumens flux
3955 lm
Rated input power
36 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-350-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3955 lm
Rated input power: 36 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-350-830
Light distribution
[T2] 133x48°
Delivered lumens flux
3955 lm
Rated input power
36 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-350-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3955 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-350-840
Light distribution
[T2] 133x48°
Delivered lumens flux
3955 lm
Rated input power
36 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-500-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 6880 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-500-740
Light distribution
[T2] 133x48°
Delivered lumens flux
6880 lm
Rated input power
50 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
143 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-500-822
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 4555 lm
Rated input power: 50 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T2] 133x48°
Delivered lumens flux
4555 lm
Rated input power
50 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
91 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-500-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 5870 lm
Rated input power: 50 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-500-827
Light distribution
[T2] 133x48°
Delivered lumens flux
5870 lm
Rated input power
50 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
122 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-500-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 5870 lm
Rated input power: 50 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-500-830
Light distribution
[T2] 133x48°
Delivered lumens flux
5870 lm
Rated input power
50 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
122 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-500-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 5870 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-500-840
Light distribution
[T2] 133x48°
Delivered lumens flux
5870 lm
Rated input power
50 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
122 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-700-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 9085 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-700-740
Light distribution
[T2] 133x48°
Delivered lumens flux
9085 lm
Rated input power
70 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
135 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-700-822
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 5875 lm
Rated input power: 70 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T2] 133x48°
Delivered lumens flux
5875 lm
Rated input power
70 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
84 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-700-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 6980 lm
Rated input power: 70 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-700-827
Light distribution
[T2] 133x48°
Delivered lumens flux
6980 lm
Rated input power
70 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-700-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 6980 lm
Rated input power: 70 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-700-830
Light distribution
[T2] 133x48°
Delivered lumens flux
6980 lm
Rated input power
70 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-2-700-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 6980 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-2-700-840
Light distribution
[T2] 133x48°
Delivered lumens flux
6980 lm
Rated input power
70 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-350-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 4510 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-350-740
Light distribution
[T2] 133x48°
Delivered lumens flux
4510 lm
Rated input power
36 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
133 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-350-822
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3265 lm
Rated input power: 36 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T2] 133x48°
Delivered lumens flux
3265 lm
Rated input power
36 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
91 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-350-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3955 lm
Rated input power: 36 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-350-827
Light distribution
[T2] 133x48°
Delivered lumens flux
3955 lm
Rated input power
36 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-350-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3955 lm
Rated input power: 36 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-350-830
Light distribution
[T2] 133x48°
Delivered lumens flux
3955 lm
Rated input power
36 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-350-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3955 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-350-840
Light distribution
[T2] 133x48°
Delivered lumens flux
3955 lm
Rated input power
36 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-500-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 6880 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-500-740
Light distribution
[T2] 133x48°
Delivered lumens flux
6880 lm
Rated input power
50 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
143 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-500-822
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 4560 lm
Rated input power: 50 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T2] 133x48°
Delivered lumens flux
4560 lm
Rated input power
50 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
91 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-500-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 5870 lm
Rated input power: 50 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-500-827
Light distribution
[T2] 133x48°
Delivered lumens flux
5870 lm
Rated input power
50 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
122 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-500-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 5870 lm
Rated input power: 50 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-500-830
Light distribution
[T2] 133x48°
Delivered lumens flux
5870 lm
Rated input power
50 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
122 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-500-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 5870 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-500-840
Light distribution
[T2] 133x48°
Delivered lumens flux
5870 lm
Rated input power
50 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
122 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-700-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 9085 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-700-740
Light distribution
[T2] 133x48°
Delivered lumens flux
9085 lm
Rated input power
70 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
135 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-700-822
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 5880 lm
Rated input power: 70 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T2] 133x48°
Delivered lumens flux
5880 lm
Rated input power
70 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
84 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-700-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 6980 lm
Rated input power: 70 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-700-827
Light distribution
[T2] 133x48°
Delivered lumens flux
6980 lm
Rated input power
70 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-700-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 6980 lm
Rated input power: 70 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-700-830
Light distribution
[T2] 133x48°
Delivered lumens flux
6980 lm
Rated input power
70 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T2-700-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 6980 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T2-700-840
Light distribution
[T2] 133x48°
Delivered lumens flux
6980 lm
Rated input power
70 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-350-740
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 4315 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-350-740
Light distribution
[T3] 143x63°
Delivered lumens flux
4315 lm
Rated input power
36 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
127 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-350-822
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 2985 lm
Rated input power: 36 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T3] 143x63°
Delivered lumens flux
2985 lm
Rated input power
36 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
83 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-350-827
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 3785 lm
Rated input power: 36 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-350-827
Light distribution
[T3] 143x63°
Delivered lumens flux
3785 lm
Rated input power
36 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
111 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-350-830
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 3785 lm
Rated input power: 36 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-350-830
Light distribution
[T3] 143x63°
Delivered lumens flux
3785 lm
Rated input power
36 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
111 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-350-840
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 3785 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-350-840
Light distribution
[T3] 143x63°
Delivered lumens flux
3785 lm
Rated input power
36 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
111 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-500-740
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 6315 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-500-740
Light distribution
[T3] 143x63°
Delivered lumens flux
6315 lm
Rated input power
50 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
131 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-500-822
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 4165 lm
Rated input power: 50 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T3] 143x63°
Delivered lumens flux
4165 lm
Rated input power
50 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
83 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-500-827
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 5390 lm
Rated input power: 50 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-500-827
Light distribution
[T3] 143x63°
Delivered lumens flux
5390 lm
Rated input power
50 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
112 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-500-830
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 5390 lm
Rated input power: 50 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-500-830
Light distribution
[T3] 143x63°
Delivered lumens flux
5390 lm
Rated input power
50 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
112 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-500-840
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 5390 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-500-840
Light distribution
[T3] 143x63°
Delivered lumens flux
5390 lm
Rated input power
50 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
122 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-700-740
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 8240 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-700-740
Light distribution
[T3] 143x63°
Delivered lumens flux
8240 lm
Rated input power
70 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
123 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-700-822
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 5370 lm
Rated input power: 70 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T3] 143x63°
Delivered lumens flux
5370 lm
Rated input power
70 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
77 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-700-827
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 6980 lm
Rated input power: 70 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-700-827
Light distribution
[T3] 143x63°
Delivered lumens flux
6980 lm
Rated input power
70 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-700-830
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 6980 lm
Rated input power: 70 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-700-830
Light distribution
[T3] 143x63°
Delivered lumens flux
6980 lm
Rated input power
70 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T3-700-840
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 6980 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T3-700-840
Light distribution
[T3] 143x63°
Delivered lumens flux
6980 lm
Rated input power
70 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-350-740
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 4520 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-350-740
Light distribution
[T4] 117x64°
Delivered lumens flux
4520 lm
Rated input power
36 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
133 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-350-822
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 3125 lm
Rated input power: 36 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T4] 117x64°
Delivered lumens flux
3125 lm
Rated input power
36 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
87 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-350-827
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 3965 lm
Rated input power: 36 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-350-827
Light distribution
[T4] 117x64°
Delivered lumens flux
3965 lm
Rated input power
36 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
117 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-350-830
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 3965 lm
Rated input power: 36 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-350-830
Light distribution
[T4] 117x64°
Delivered lumens flux
3965 lm
Rated input power
36 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
117 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-350-840
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 3965 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-350-840
Light distribution
[T4] 117x64°
Delivered lumens flux
3965 lm
Rated input power
36 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
117 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-500-740
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 6565 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-500-740
Light distribution
[T4] 117x64°
Delivered lumens flux
6565 lm
Rated input power
50 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
136 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-500-822
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 4355 lm
Rated input power: 50 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T4] 117x64°
Delivered lumens flux
4355 lm
Rated input power
50 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
87 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-500-827
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 5605 lm
Rated input power: 50 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-500-827
Light distribution
[T4] 117x64°
Delivered lumens flux
5605 lm
Rated input power
50 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-500-830
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 5605 lm
Rated input power: 50 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-500-830
Light distribution
[T4] 117x64°
Delivered lumens flux
5605 lm
Rated input power
50 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-500-840
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 5605 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-500-840
Light distribution
[T4] 117x64°
Delivered lumens flux
5605 lm
Rated input power
50 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-700-740
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 8705 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-700-740
Light distribution
[T4] 117x64°
Delivered lumens flux
8705 lm
Rated input power
70 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
129 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-700-822
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 5620 lm
Rated input power: 70 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T4] 117x64°
Delivered lumens flux
5620 lm
Rated input power
70 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
80 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-700-827
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 7255 lm
Rated input power: 70 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-700-827
Light distribution
[T4] 117x64°
Delivered lumens flux
7255 lm
Rated input power
70 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
108 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-700-830
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 7255 lm
Rated input power: 70 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-700-830
Light distribution
[T4] 117x64°
Delivered lumens flux
7255 lm
Rated input power
70 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
108 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T4-700-840
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 7255 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T4-700-840
Light distribution
[T4] 117x64°
Delivered lumens flux
7255 lm
Rated input power
70 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
108 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-350-740
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 4690 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-350-740
Light distribution
[T5] 117°
Delivered lumens flux
4690 lm
Rated input power
36 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
138 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-350-822
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 3285 lm
Rated input power: 36 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T5] 117°
Delivered lumens flux
3285 lm
Rated input power
36 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
91 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-350-827
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 4115 lm
Rated input power: 36 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-350-827
Light distribution
[T5] 117°
Delivered lumens flux
4115 lm
Rated input power
36 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
121 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-350-830
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 4115 lm
Rated input power: 36 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-350-830
Light distribution
[T5] 117°
Delivered lumens flux
4115 lm
Rated input power
36 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
121 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-350-840
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 4115 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-350-840
Light distribution
[T5] 117°
Delivered lumens flux
4115 lm
Rated input power
36 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
121 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-500-740
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 6920 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-500-740
Light distribution
[T5] 117°
Delivered lumens flux
6920 lm
Rated input power
50 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
144 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-500-822
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 4585 lm
Rated input power: 50 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T5] 117°
Delivered lumens flux
4585 lm
Rated input power
50 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
92 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-500-827
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 5910 lm
Rated input power: 50 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-500-827
Light distribution
[T5] 117°
Delivered lumens flux
5910 lm
Rated input power
50 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
123 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-500-830
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 5910 lm
Rated input power: 50 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-500-830
Light distribution
[T5] 117°
Delivered lumens flux
5910 lm
Rated input power
50 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
123 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-500-840
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 5910 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-500-840
Light distribution
[T5] 117°
Delivered lumens flux
5910 lm
Rated input power
50 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
123 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-700-740
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 8940 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-700-740
Light distribution
[T5] 117°
Delivered lumens flux
8940 lm
Rated input power
70 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
133 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-700-822
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 5915 lm
Rated input power: 70 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[T5] 117°
Delivered lumens flux
5915 lm
Rated input power
70 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
85 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-700-827
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 7645 lm
Rated input power: 70 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-700-827
Light distribution
[T5] 117°
Delivered lumens flux
7645 lm
Rated input power
70 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-700-830
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 7645 lm
Rated input power: 70 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-700-830
Light distribution
[T5] 117°
Delivered lumens flux
7645 lm
Rated input power
70 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-T5-700-840
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 7645 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-T5-700-840
Light distribution
[T5] 117°
Delivered lumens flux
7645 lm
Rated input power
70 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-350-740
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 4690 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-350-740
Light distribution
[P4] 20x78°
Delivered lumens flux
4690 lm
Rated input power
36 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
138 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-350-822
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 3235 lm
Rated input power: 36 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[P4] 20x78°
Delivered lumens flux
3235 lm
Rated input power
36 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
90 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-350-827
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 4115 lm
Rated input power: 36 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-350-827
Light distribution
[P4] 20x78°
Delivered lumens flux
4115 lm
Rated input power
36 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
121 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-350-830
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 4115 lm
Rated input power: 36 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-350-830
Light distribution
[P4] 20x78°
Delivered lumens flux
4115 lm
Rated input power
36 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
121 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-350-840
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 4115 lm
Rated input power: 36 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-350-840
Light distribution
[P4] 20x78°
Delivered lumens flux
4115 lm
Rated input power
36 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
121 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B0-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-500-740
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 6830 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-500-740
Light distribution
[P4] 20x78°
Delivered lumens flux
6830 lm
Rated input power
50 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
142 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-500-822
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 4590 lm
Rated input power: 50 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[P4] 20x78°
Delivered lumens flux
4590 lm
Rated input power
50 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
92 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-500-827
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 5830 lm
Rated input power: 50 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-500-827
Light distribution
[P4] 20x78°
Delivered lumens flux
5830 lm
Rated input power
50 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
121 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-500-830
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 5830 lm
Rated input power: 50 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-500-830
Light distribution
[P4] 20x78°
Delivered lumens flux
5830 lm
Rated input power
50 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
121 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-500-840
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 5830 lm
Rated input power: 50 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-500-840
Light distribution
[P4] 20x78°
Delivered lumens flux
5830 lm
Rated input power
50 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
121 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-700-740
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 9025 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-700-740
Light distribution
[P4] 20x78°
Delivered lumens flux
9025 lm
Rated input power
70 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
134 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-700-822
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 5940 lm
Rated input power: 70 W
Colour temperature: 2200 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
Light distribution
[P4] 20x78°
Delivered lumens flux
5940 lm
Rated input power
70 W
Colour temperature
2200 K CRI 80
Luminaire efficacy
85 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-700-827
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 7545 lm
Rated input power: 70 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-700-827
Light distribution
[P4] 20x78°
Delivered lumens flux
7545 lm
Rated input power
70 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
112 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-700-830
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 7545 lm
Rated input power: 70 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-700-830
Light distribution
[P4] 20x78°
Delivered lumens flux
7545 lm
Rated input power
70 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
112 lm/W
Lamp
32 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000
Variant code: LP4091.861-EN-P4-700-840
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 7545 lm
Rated input power: 70 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4091.861-EN-P4-700-840
Light distribution
[P4] 20x78°
Delivered lumens flux
7545 lm
Rated input power
70 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
112 lm/W
Lamp
32 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B10 (hour)
>102,000
Lifetime L90B50 (hour)
>102,000

Extras


Backlight Shield

[BS]

Backlight Shield

Light output
Constant light output

[CLO]

Constant light output

Light output
Prismatic Glass

[PG]

Prismatic Glass

Light output
Motion sensor

[MS]

Motion sensor

Consult the factory
120-277V 50/60Hz

[UNI]

120-277V 50/60Hz

Consult the factory
Double powder coating

[DPC]

Double powder coating

Luminaire body options

Poles (Included)



All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Type I, Asymmetric, Side throw
[T1]

Type I, Asymmetric, Side throw

Type II, Asymmetric, Side throw
[T2]

Type II, Asymmetric, Side throw

Type III, Asymmetric, Side throw
[T3]

Type III, Asymmetric, Side throw

Type IV, Asymmetric, Forward throw
[T4]

Type IV, Asymmetric, Forward throw

Type V, Symmetric
[T5]

Type V, Symmetric

Special pedestrian road distribution-right side traffic
[P4]

Special pedestrian road distribution-right side traffic

Drive current


350 mA
[350]

350 mA

500 mA
[500]

500 mA

700 mA
[700]

700 mA

Colour temperature


2200 K CRI 80
[822]

2200 K CRI 80

2700 K CRI 80
[827]

2700 K CRI 80

3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

4000 K CRI 80
[840]

4000 K CRI 80

Options

Control

Product colours


On/Off
[ONOFF]

On/Off

DALI
[DALI]

DALI

AutoDIM
[AUTO]

AutoDIM

StepDIM
[STEP]

StepDIM

Product colours


Black
[HM1]

Black

Dark grey
[HM2]

Dark grey

Anthracite grey
[HM3]

Anthracite grey

Light grey
[HM4]

Light grey

White
[HM5]

White

Bronze
[HM6]

Bronze

Custom colour (Please specify RAL code)
[CC]

Custom colour (Please specify RAL code)
