HELIOS AFX 1 Module

HELIOS AFX 1 ModuleHELIOS AFX 1 ModuleHELIOS AFX 1 Module
HELIOS AFX 1 ModuleHELIOS AFX 1 ModuleHELIOS AFX 1 Module

LP4036.861-EN

CEUKCAIK08IP66Class I
Variants
Light distribution
[P4] 20x78°, [T1] 111x48°, [T2] 133x48°, [T2] 149x54°, [T3] 143x63°, [T4] 117x64°, [T5] 117°
Delivered lumens flux
1975 - 4540 lm
Rated input power
18 - 35 W
Colour temperature
2700 K CRI 80, 3000 K CRI 80, 4000 K CRI 70, 4000 K CRI 80
BUG rating
B1-U0-G1, B1-U0-G0, B2-U0-G1, B0-U0-G0, B2-U0-G0
Lifetime L90B50 (hour)
>102, 000
Lifetime L80B50 (hour)
>102, 000
Options
Control
On/Off, DALI, AutoDIM, StepDIM
Product colours
BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
Extras
Consult the factory
120-277V 50/60Hz

Technical details



Certificates
CE, UKCA
Mounting
Direct pole or side bracket mountable. Spigot: Ø60 mm x 100 mm
Housing
Corrosion resistant, marine grade aluminum housing
Finishing
Chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (AISI 304 / EN 1.4301 grade)
Gasket
Silicone
Lens / Reflector
PMMA lens with high optical efficiency
Glass / Diffusor
Custom Design PMMA Diffusor
Impact protection
IK08
Ingress protection
IP66
Input voltage
220-240V 50/60Hz
Insulation class
Class I
Wind catching area (EPA)
0.24 m²
Weight
4.86 kg
LED module
High power LEDs on metal-core PCB
Driver
Internal LED driver
Driver surge protection
10/6 kV
Power factor
> 0.95
Through wiring
Single cable entry
Operating temperature
-40...50°C
Cable
0.5 m of flexible cable
Packing box dimensions
50*50*103 cm

Downloads


Variants


Light distribution
Type I, Asymmetric, Side throw
[T1] Type I, Asymmetric, Side throw - 111x48°
Type II, Asymmetric, Side throw
[T2] Type II, Asymmetric, Side throw - 133x48°
Type II, Asymmetric, Side throw
[T2] Type II, Asymmetric, Side throw - 149x54°
Type III, Asymmetric, Side throw
[T3] Type III, Asymmetric, Side throw - 143x63°
Type IV, Asymmetric, Forward throw
[T4] Type IV, Asymmetric, Forward throw - 117x64°
Type V, Symmetric
[T5] Type V, Symmetric - 117°
Special pedestrian road distribution-right side traffic
[P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux
1975 lm
1980 lm
2010 lm
2055 lm
2115 lm
2155 lm
2255 lm
2260 lm
2290 lm
2345 lm
2415 lm
2695 lm
2805 lm
2830 lm
2895 lm
2915 lm
2935 lm
2955 lm
3150 lm
3275 lm
3320 lm
3390 lm
3400 lm
3440 lm
3445 lm
3490 lm
3630 lm
3665 lm
3750 lm
3770 lm
3800 lm
3820 lm
4140 lm
4310 lm
4370 lm
4445 lm
4480 lm
4510 lm
4540 lm
Rated input power
18 W
25 W
35 W
Colour temperature
2700 K CRI 80
3000 K CRI 80
4000 K CRI 70
4000 K CRI 80

Variant code

Light distribution

Delivered lumens flux

Rated input power

Colour temperature

Control


Variant code: LP4036.861-EN-T1-350-740
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 2415 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-350-740
Light distribution
[T1] 111x48°
Delivered lumens flux
2415 lm
Rated input power
18 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
134 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-350-827
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 2115 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-350-827
Light distribution
[T1] 111x48°
Delivered lumens flux
2115 lm
Rated input power
18 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
117 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-350-830
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 2115 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-350-830
Light distribution
[T1] 111x48°
Delivered lumens flux
2115 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
117 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-350-840
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 2115 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-350-840
Light distribution
[T1] 111x48°
Delivered lumens flux
2115 lm
Rated input power
18 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
117 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-500-740
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 3390 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-500-740
Light distribution
[T1] 111x48°
Delivered lumens flux
3390 lm
Rated input power
25 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
135 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-500-827
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 2895 lm
Rated input power: 25 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-500-827
Light distribution
[T1] 111x48°
Delivered lumens flux
2895 lm
Rated input power
25 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
115 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-500-830
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 2895 lm
Rated input power: 25 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-500-830
Light distribution
[T1] 111x48°
Delivered lumens flux
2895 lm
Rated input power
25 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
115 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-500-840
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 2895 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-500-840
Light distribution
[T1] 111x48°
Delivered lumens flux
2895 lm
Rated input power
25 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
115 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-700-740
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 4445 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-700-740
Light distribution
[T1] 111x48°
Delivered lumens flux
4445 lm
Rated input power
35 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
127 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-700-827
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 3750 lm
Rated input power: 35 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-700-827
Light distribution
[T1] 111x48°
Delivered lumens flux
3750 lm
Rated input power
35 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-700-830
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 3750 lm
Rated input power: 35 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-700-830
Light distribution
[T1] 111x48°
Delivered lumens flux
3750 lm
Rated input power
35 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T1-700-840
Light distribution: [T1] Type I, Asymmetric, Side throw - 111x48°
Delivered lumens flux: 3750 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T1-700-840
Light distribution
[T1] 111x48°
Delivered lumens flux
3750 lm
Rated input power
35 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-350-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 2255 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-350-740
Light distribution
[T2] 133x48°
Delivered lumens flux
2255 lm
Rated input power
18 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
125 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B0-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-350-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 1975 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-350-827
Light distribution
[T2] 133x48°
Delivered lumens flux
1975 lm
Rated input power
18 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
109 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-350-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 1975 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-350-830
Light distribution
[T2] 133x48°
Delivered lumens flux
1975 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
109 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-350-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 1975 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-350-840
Light distribution
[T2] 133x48°
Delivered lumens flux
1975 lm
Rated input power
18 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
109 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B0-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-500-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3440 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-500-740
Light distribution
[T2] 133x48°
Delivered lumens flux
3440 lm
Rated input power
25 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
137 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-500-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 2935 lm
Rated input power: 25 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-500-827
Light distribution
[T2] 133x48°
Delivered lumens flux
2935 lm
Rated input power
25 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
117 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-500-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 2935 lm
Rated input power: 25 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-500-830
Light distribution
[T2] 133x48°
Delivered lumens flux
2935 lm
Rated input power
25 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
117 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-500-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 2935 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-500-840
Light distribution
[T2] 133x48°
Delivered lumens flux
2935 lm
Rated input power
25 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
117 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-700-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 4510 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-700-740
Light distribution
[T2] 133x48°
Delivered lumens flux
4510 lm
Rated input power
35 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
128 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-700-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3800 lm
Rated input power: 35 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-700-827
Light distribution
[T2] 133x48°
Delivered lumens flux
3800 lm
Rated input power
35 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
108 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-700-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3800 lm
Rated input power: 35 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-700-830
Light distribution
[T2] 133x48°
Delivered lumens flux
3800 lm
Rated input power
35 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
108 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-700-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 133x48°
Delivered lumens flux: 3800 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-700-840
Light distribution
[T2] 133x48°
Delivered lumens flux
3800 lm
Rated input power
35 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
108 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-350-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 2290 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-350-740
Light distribution
[T2] 149x54°
Delivered lumens flux
2290 lm
Rated input power
18 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
127 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-350-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 2010 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-350-827
Light distribution
[T2] 149x54°
Delivered lumens flux
2010 lm
Rated input power
18 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
111 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-350-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 2010 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-350-830
Light distribution
[T2] 149x54°
Delivered lumens flux
2010 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
111 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-350-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 2010 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-350-840
Light distribution
[T2] 149x54°
Delivered lumens flux
2010 lm
Rated input power
18 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
111 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-500-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 3320 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-500-740
Light distribution
[T2] 149x54°
Delivered lumens flux
3320 lm
Rated input power
25 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
132 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-500-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 2830 lm
Rated input power: 25 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-500-827
Light distribution
[T2] 149x54°
Delivered lumens flux
2830 lm
Rated input power
25 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
113 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-500-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 2830 lm
Rated input power: 25 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-500-830
Light distribution
[T2] 149x54°
Delivered lumens flux
2830 lm
Rated input power
25 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
113 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-500-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 2830 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-500-840
Light distribution
[T2] 149x54°
Delivered lumens flux
2830 lm
Rated input power
25 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
113 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-700-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 4370 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-700-740
Light distribution
[T2] 149x54°
Delivered lumens flux
4370 lm
Rated input power
35 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
124 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-700-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 3665 lm
Rated input power: 35 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-700-827
Light distribution
[T2] 149x54°
Delivered lumens flux
3665 lm
Rated input power
35 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-700-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 3665 lm
Rated input power: 35 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-700-830
Light distribution
[T2] 149x54°
Delivered lumens flux
3665 lm
Rated input power
35 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T2-2-700-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 149x54°
Delivered lumens flux: 3665 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T2-2-700-840
Light distribution
[T2] 149x54°
Delivered lumens flux
3665 lm
Rated input power
35 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
104 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-350-740
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 2155 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-350-740
Light distribution
[T3] 143x63°
Delivered lumens flux
2155 lm
Rated input power
18 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
119 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-350-827
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 1980 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-350-827
Light distribution
[T3] 143x63°
Delivered lumens flux
1980 lm
Rated input power
18 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
110 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-350-830
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 1980 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-350-830
Light distribution
[T3] 143x63°
Delivered lumens flux
1980 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
110 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-350-840
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 1980 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-350-840
Light distribution
[T3] 143x63°
Delivered lumens flux
1980 lm
Rated input power
18 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
110 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-500-740
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 3150 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-500-740
Light distribution
[T3] 143x63°
Delivered lumens flux
3150 lm
Rated input power
25 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
126 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-500-827
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 2695 lm
Rated input power: 25 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-500-827
Light distribution
[T3] 143x63°
Delivered lumens flux
2695 lm
Rated input power
25 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-500-830
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 2695 lm
Rated input power: 25 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-500-830
Light distribution
[T3] 143x63°
Delivered lumens flux
2695 lm
Rated input power
25 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-500-840
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 2695 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-500-840
Light distribution
[T3] 143x63°
Delivered lumens flux
2695 lm
Rated input power
25 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-700-740
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 4140 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-700-740
Light distribution
[T3] 143x63°
Delivered lumens flux
4140 lm
Rated input power
35 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
118 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-700-827
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 3490 lm
Rated input power: 35 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-700-827
Light distribution
[T3] 143x63°
Delivered lumens flux
3490 lm
Rated input power
35 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
99 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-700-830
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 3490 lm
Rated input power: 35 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-700-830
Light distribution
[T3] 143x63°
Delivered lumens flux
3490 lm
Rated input power
35 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
99 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T3-700-840
Light distribution: [T3] Type III, Asymmetric, Side throw - 143x63°
Delivered lumens flux: 3490 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T3-700-840
Light distribution
[T3] 143x63°
Delivered lumens flux
3490 lm
Rated input power
35 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
99 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-350-740
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 2260 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-350-740
Light distribution
[T4] 117x64°
Delivered lumens flux
2260 lm
Rated input power
18 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
125 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-350-827
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 1980 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-350-827
Light distribution
[T4] 117x64°
Delivered lumens flux
1980 lm
Rated input power
18 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
110 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-350-830
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 1980 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-350-830
Light distribution
[T4] 117x64°
Delivered lumens flux
1980 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
110 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-350-840
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 1980 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-350-840
Light distribution
[T4] 117x64°
Delivered lumens flux
1980 lm
Rated input power
18 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
110 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-500-740
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 3275 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-500-740
Light distribution
[T4] 117x64°
Delivered lumens flux
3275 lm
Rated input power
25 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
131 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-500-827
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 2805 lm
Rated input power: 25 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-500-827
Light distribution
[T4] 117x64°
Delivered lumens flux
2805 lm
Rated input power
25 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
112 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-500-830
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 2805 lm
Rated input power: 25 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-500-830
Light distribution
[T4] 117x64°
Delivered lumens flux
2805 lm
Rated input power
25 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
112 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-500-840
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 2805 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-500-840
Light distribution
[T4] 117x64°
Delivered lumens flux
2805 lm
Rated input power
25 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
112 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-700-740
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 4310 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-700-740
Light distribution
[T4] 117x64°
Delivered lumens flux
4310 lm
Rated input power
35 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
123 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-700-827
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 3630 lm
Rated input power: 35 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-700-827
Light distribution
[T4] 117x64°
Delivered lumens flux
3630 lm
Rated input power
35 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
103 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-700-830
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 3630 lm
Rated input power: 35 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-700-830
Light distribution
[T4] 117x64°
Delivered lumens flux
3630 lm
Rated input power
35 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
103 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T4-700-840
Light distribution: [T4] Type IV, Asymmetric, Forward throw - 117x64°
Delivered lumens flux: 3630 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T4-700-840
Light distribution
[T4] 117x64°
Delivered lumens flux
3630 lm
Rated input power
35 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
103 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-350-740
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 2345 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-350-740
Light distribution
[T5] 117°
Delivered lumens flux
2345 lm
Rated input power
18 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
130 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-350-827
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 2055 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-350-827
Light distribution
[T5] 117°
Delivered lumens flux
2055 lm
Rated input power
18 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-350-830
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 2055 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-350-830
Light distribution
[T5] 117°
Delivered lumens flux
2055 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-350-840
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 2055 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-350-840
Light distribution
[T5] 117°
Delivered lumens flux
2055 lm
Rated input power
18 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-500-740
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 3445 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-500-740
Light distribution
[T5] 117°
Delivered lumens flux
3445 lm
Rated input power
25 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
137 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-500-827
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 2955 lm
Rated input power: 25 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-500-827
Light distribution
[T5] 117°
Delivered lumens flux
2955 lm
Rated input power
25 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
118 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-500-830
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 2955 lm
Rated input power: 25 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-500-830
Light distribution
[T5] 117°
Delivered lumens flux
2955 lm
Rated input power
25 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
118 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-500-840
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 2955 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-500-840
Light distribution
[T5] 117°
Delivered lumens flux
2955 lm
Rated input power
25 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
118 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-700-740
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 4540 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-700-740
Light distribution
[T5] 117°
Delivered lumens flux
4540 lm
Rated input power
35 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
129 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-700-827
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 3820 lm
Rated input power: 35 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-700-827
Light distribution
[T5] 117°
Delivered lumens flux
3820 lm
Rated input power
35 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
109 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-700-830
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 3820 lm
Rated input power: 35 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-700-830
Light distribution
[T5] 117°
Delivered lumens flux
3820 lm
Rated input power
35 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
109 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B2-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-T5-700-840
Light distribution: [T5] Type V, Symmetric - 117°
Delivered lumens flux: 3820 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-T5-700-840
Light distribution
[T5] 117°
Delivered lumens flux
3820 lm
Rated input power
35 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
109 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B2-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-350-740
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 2345 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-350-740
Light distribution
[P4] 20x78°
Delivered lumens flux
2345 lm
Rated input power
18 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
130 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-350-827
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 2055 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-350-827
Light distribution
[P4] 20x78°
Delivered lumens flux
2055 lm
Rated input power
18 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-350-830
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 2055 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-350-830
Light distribution
[P4] 20x78°
Delivered lumens flux
2055 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-350-840
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 2055 lm
Rated input power: 18 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-350-840
Light distribution
[P4] 20x78°
Delivered lumens flux
2055 lm
Rated input power
18 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
114 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-500-740
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 3400 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-500-740
Light distribution
[P4] 20x78°
Delivered lumens flux
3400 lm
Rated input power
25 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
136 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-500-827
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 2915 lm
Rated input power: 25 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-500-827
Light distribution
[P4] 20x78°
Delivered lumens flux
2915 lm
Rated input power
25 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-500-830
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 2915 lm
Rated input power: 25 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-500-830
Light distribution
[P4] 20x78°
Delivered lumens flux
2915 lm
Rated input power
25 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-500-840
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 2915 lm
Rated input power: 25 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-500-840
Light distribution
[P4] 20x78°
Delivered lumens flux
2915 lm
Rated input power
25 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
116 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-700-740
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 4480 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-700-740
Light distribution
[P4] 20x78°
Delivered lumens flux
4480 lm
Rated input power
35 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
128 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-700-827
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 3770 lm
Rated input power: 35 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-700-827
Light distribution
[P4] 20x78°
Delivered lumens flux
3770 lm
Rated input power
35 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-700-830
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 3770 lm
Rated input power: 35 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-700-830
Light distribution
[P4] 20x78°
Delivered lumens flux
3770 lm
Rated input power
35 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
16 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LP4036.861-EN-P4-700-840
Light distribution: [P4] Special pedestrian road distribution-right side traffic - 20x78°
Delivered lumens flux: 3770 lm
Rated input power: 35 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LP4036.861-EN-P4-700-840
Light distribution
[P4] 20x78°
Delivered lumens flux
3770 lm
Rated input power
35 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
16 LED
MacAdam Ellipse
4 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000

Poles (To be ordered separately)



All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Type I, Asymmetric, Side throw
[T1]

Type I, Asymmetric, Side throw

Type II, Asymmetric, Side throw
[T2]

Type II, Asymmetric, Side throw

Type III, Asymmetric, Side throw
[T3]

Type III, Asymmetric, Side throw

Type IV, Asymmetric, Forward throw
[T4]

Type IV, Asymmetric, Forward throw

Type V, Symmetric
[T5]

Type V, Symmetric

Special pedestrian road distribution-right side traffic
[P4]

Special pedestrian road distribution-right side traffic

Drive current


350 mA
[350]

350 mA

500 mA
[500]

500 mA

700 mA
[700]

700 mA

Colour temperature


2700 K CRI 80
[827]

2700 K CRI 80

3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

4000 K CRI 80
[840]

4000 K CRI 80

Options

Control

Product colours


On/Off
[ONOFF]

On/Off

DALI
[DALI]

DALI

AutoDIM
[AUTO]

AutoDIM

StepDIM
[STEP]

StepDIM

Product colours


Black
[HM1]

Black

Dark grey
[HM2]

Dark grey

Anthracite grey
[HM3]

Anthracite grey

Light grey
[HM4]

Light grey

White
[HM5]

White

Bronze
[HM6]

Bronze

Custom colour (Please specify RAL code)
[CC]

Custom colour (Please specify RAL code)

Extras

Consult the factory


120-277V 50/60Hz
[UNI]

120-277V 50/60Hz
