REXA AFX Midi 4 Module Duo

Name: REXA AFX Midi 4 Module Duo
Brand: HEPER
SKU: LL2047.874-EN
Availability: InStock

UPCOMING

LL2047.874-EN

Downloads

Photometry files (IES)

2.91 MB ZIP

Photometry files (LDT)

1.69 MB ZIP

Technical drawing

0.05 MB ZIP

Technical drawing (Image)

0.05 MB PNG

Certificate files

1.12 MB ZIP

Light distribution

[T1] 119x46°, [T2] 136x52°, [T2-2] 143x58°, [T3] 130x67°, [T4] 120x67°, [T5] 127°

Luminaire luminous flux

13152 - 27192 lm

Rated input power

144 - 210 W

CCT

2700K, 3000K, 4000K

CRI

Ra80

Control

On/Off, DALI

Product colours

Height

08m - 06m, 08m - 08m

Luminaire efficacy

85 - 129 lm/W

Colour deviation

3 SDCM

Housing

Marine grade aluminum housing

Driver

Integral LED driver

Input voltage

220-240V 50/60Hz

Configurator

Project name

Type

Quantity

Date

Note

Variant order code

LL2047.874-EN-_-_-_-_-EN-C1-_-_

Variants

Light distribution

[T1]
Type I, Asymmetric, Side throw
119x46°

[T2]
Type II, Asymmetric, Side throw
136x52°

[T2-2]
Type II, Asymmetric, Side throw
143x58°

[T3]
Type III, Asymmetric, Side throw
130x67°

[T4]
Type IV, Asymmetric, Forward throw
120x67°

[T5]
Type V, Symmetric
127°

Rated input power

[700]
144 W

[880]
176 W

[1050]
210 W

Colour temperature

[827]
2700 K CRI 80

[830]
3000 K CRI 80

[840]
4000 K CRI 80

Options

Control

[ONOFF]
On/Off

[DALI]
DALI

Product colours

[HM1]

Black

[CC]

Custom colour (Please specify RAL code)

[7035]

Light grey (RAL 7035)

Height

[H0806]
08m - 06m

[H0808]
08m - 08m

Technical details

Certificates

CE, UKCA

Impact protection

IK08

Ingress protection

IP66

Insulation class

Class I

All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions

Variants

Light distribution

Drive current

[T1]

Type I, Asymmetric, Side throw

[T2]

Type II, Asymmetric, Side throw

[T2-2]

Type II, Asymmetric, Side throw

[T3]

Type III, Asymmetric, Side throw

[T4]

Type IV, Asymmetric, Forward throw

[T5]

Type V, Symmetric

Drive current

[700]

700 mA

[1050]

1050 mA

Colour temperature

[827]

2700 K CRI 80

[830]

3000 K CRI 80

[840]

4000 K CRI 80

Options

Control

Product colours

[ONOFF]

On/Off

[DALI]

DALI

Product colours

[HM1]

Black

[CC]

Custom colour (Please specify RAL code)

[7035]

Light grey (RAL 7035)
