    D-LIGHT L ML 4 Module

    PHASED-OUT
    D-LIGHT L ML 4 ModuleD-LIGHT L ML 4 Module
    D-LIGHT L ML 4 ModuleD-LIGHT L ML 4 Module

    LL2024.674-EN

    CEENECUKCAIK08IP66Class I
    Variants
    Light distribution
    [T2] 130x85°
    Delivered lumens flux
    11783 - 14255 lm
    Rated input power
    137 W
    Colour temperature
    3000 K CRI 70, 3000 K CRI 80, 4000 K CRI 70
    BUG rating
    B2-U0-G2, B3-U0-G2
    Lifetime L90B50 (hour)
    >60, 000
    Options
    Control
    On/Off, DALI, AutoDIM, StepDIM
    Product colours
    Anthracite greyLight greyCustom colour (Please specify RAL code)
    Extras
    External surge protection
    10 kV
    Connectivity
    NEMA socket - 7 Pin
    Light output
    Constant light output
    Consult the factory
    Class II, 120-277V 50/60Hz
    Luminaire body options
    Double powder coating

    Technical details


    Certificates
    CE, ENEC, UKCA
    Mounting
    Direct pole or side bracket mountable. Spigot: Ø60 mm x 100 mm
    Tilt angle
    +15°/-15°
    Housing
    Corrosion resistant, die-cast, marine grade aluminum housing
    Finishing
    Chromate conversion pretreatment followed by electrostatic powder coating
    Fasteners
    Stainless steel (AISI 304 / EN 1.4301 grade)
    Gasket
    EPDM gasket (Shore A 20-25)
    Lens / Reflector
    High reflectance aluminium coating, multifaceted micro reflector
    Glass / Diffusor
    Bio-based, enriched with bisphenol A diffusor
    Impact protection
    IK08
    Ingress protection
    IP66
    Input voltage
    220-240V 50/60Hz
    Insulation class
    Class I
    Wind catching area (EPA)
    0.27 m²
    Weight
    9.75 kg
    LED module
    Multi-chip high power LEDs on metal-core PCB
    Driver
    Integral LED driver
    Driver surge protection
    8/6 kV
    Power factor
    > 0.99
    Through wiring
    Single cable entry
    Operating temperature
    -40...50°C
    Cable
    0.5 m of flexible cable
    Pole detail
    Poles are supplied with flange plate. Flange cover and anchorage can be ordered separately. Embedded base is optional
    Notes
    This product can be supplied with Insulation class (Class II) upon request. Please contact factory.

    Downloads

    Variants

    Light distribution
    Type II, Asymmetric, Side throw
    [T2] Type II, Asymmetric, Side throw - 130x85°
    Delivered lumens flux
    11783 lm
    13795 lm
    14255 lm
    Rated input power
    137 W
    Colour temperature
    3000 K CRI 70
    3000 K CRI 80
    4000 K CRI 70

    Variant code

    Light distribution

    Delivered lumens flux

    Rated input power

    Colour temperature

    Control

    Variant code: LL2024.674-EN-T2-700-730
    Light distribution: [T2] Type II, Asymmetric, Side throw - 130x85°
    Delivered lumens flux: 14255 lm
    Rated input power: 137 W
    Colour temperature: 3000 K CRI 70
    Control: On/Off, DALI, AutoDIM, StepDIM
    LL2024.674-EN-T2-700-730
    Light distribution
    [T2] 130x85°
    Delivered lumens flux
    14255 lm
    Rated input power
    137 W
    Colour temperature
    3000 K CRI 70
    Luminaire efficacy
    104 lm/W
    Lamp
    16 LED
    MacAdam Ellipse
    5 SDCM
    BUG rating
    B3-U0-G2
    Lifetime L90B50 (hour)
    >60,000
    Variant code: LL2024.674-EN-T2-700-740
    Light distribution: [T2] Type II, Asymmetric, Side throw - 130x85°
    Delivered lumens flux: 13795 lm
    Rated input power: 137 W
    Colour temperature: 4000 K CRI 70
    Control: On/Off, DALI, AutoDIM, StepDIM
    LL2024.674-EN-T2-700-740
    Light distribution
    [T2] 130x85°
    Delivered lumens flux
    13795 lm
    Rated input power
    137 W
    Colour temperature
    4000 K CRI 70
    Luminaire efficacy
    100 lm/W
    Lamp
    16 LED
    MacAdam Ellipse
    5 SDCM
    BUG rating
    B3-U0-G2
    Lifetime L90B50 (hour)
    >60,000
    Variant code: LL2024.674-EN-T2-700-830
    Light distribution: [T2] Type II, Asymmetric, Side throw - 130x85°
    Delivered lumens flux: 11783 lm
    Rated input power: 137 W
    Colour temperature: 3000 K CRI 80
    Control: On/Off, DALI, AutoDIM, StepDIM
    LL2024.674-EN-T2-700-830
    Light distribution
    [T2] 130x85°
    Delivered lumens flux
    11783 lm
    Rated input power
    137 W
    Colour temperature
    3000 K CRI 80
    Luminaire efficacy
    86 lm/W
    Lamp
    16 LED
    MacAdam Ellipse
    5 SDCM
    BUG rating
    B2-U0-G2
    Lifetime L90B50 (hour)
    >60,000

    Extras

    10 kV

    [SP10]

    10 kV

    External surge protection
    NEMA socket - 7 Pin

    [NM7]

    NEMA socket - 7 Pin

    Connectivity
    Constant light output

    [CLO]

    Constant light output

    Light output
    Class II

    [C2]

    Class II

    Consult the factory
    120-277V 50/60Hz

    [UNI]

    120-277V 50/60Hz

    Consult the factory
    Double powder coating

    [DPC]

    Double powder coating

    Luminaire body options

    Related products

    All flux and power values derived following appropriate IES, CIE and applicable standards.
