D-LIGHT ML 2 Module

D-LIGHT ML 2 ModuleD-LIGHT ML 2 Module
D-LIGHT ML 2 ModuleD-LIGHT ML 2 Module

LL2023.672-EN

CEENECUKCAIK08IP66Class I
Variants
Light distribution
[T2] 130x85°
Delivered lumens flux
5891 - 7127 lm
Rated input power
68 W
Colour temperature
3000 K CRI 70, 3000 K CRI 80, 4000 K CRI 70
BUG rating
B1-U0-G1, B2-U0-G1
Lifetime L90B50 (hour)
>60, 000
Lifetime L80B50 (hour)
>60, 000
Options
Control
On/Off, DALI, AutoDIM, StepDIM
Product colours
Anthracite greyLight greyCustom colour (Please specify RAL code)
Extras
External surge protection
10 kV
Connectivity
NEMA socket - 7 Pin
Light output
Constant light output
Consult the factory
Class II, 120-277V 50/60Hz
Luminaire body options
Double powder coating

Technical details



Certificates
CE, ENEC, UKCA
Mounting
Direct pole or side bracket mountable. Spigot: Ø60 mm x 100 mm
Tilt angle
+15°/-15°
Housing
Corrosion resistant, die-cast, marine grade aluminum housing
Finishing
Chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (AISI 304 / EN 1.4301 grade)
Gasket
EPDM gasket (Shore A 20-25)
Lens / Reflector
High reflectance aluminium coating, multifaceted micro reflector
Glass / Diffusor
Bio-based, enriched with bisphenol A diffusor
Impact protection
IK08
Ingress protection
IP66
Input voltage
220-240V 50/60Hz
Insulation class
Class I
Wind catching area (EPA)
0.08 m²
Weight
8.63 kg
LED module
Multi-chip high power LEDs on metal-core PCB
Driver
Integral LED driver
Driver surge protection
10/6 kV
Power factor
> 0.95
Through wiring
Single cable entry
Operating temperature
-40...50°C
Cable
0.5 m of flexible cable
Notes
This product can be supplied with Insulation class (Class II) upon request. Please contact factory.

Downloads


Variants


Light distribution
Type II, Asymmetric, Side throw
[T2] Type II, Asymmetric, Side throw - 130x85°
Delivered lumens flux
5891 lm
6897 lm
7127 lm
Rated input power
68 W
Colour temperature
3000 K CRI 70
3000 K CRI 80
4000 K CRI 70

Variant code

Light distribution

Delivered lumens flux

Rated input power

Colour temperature

Control


Variant code: LL2023.672-EN-T2-700-730
Light distribution: [T2] Type II, Asymmetric, Side throw - 130x85°
Delivered lumens flux: 7127 lm
Rated input power: 68 W
Colour temperature: 3000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LL2023.672-EN-T2-700-730
Light distribution
[T2] 130x85°
Delivered lumens flux
7127 lm
Rated input power
68 W
Colour temperature
3000 K CRI 70
Luminaire efficacy
101 lm/W
Lamp
8 LED
MacAdam Ellipse
5 SDCM
BUG rating
B2-U0-G1
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000
Variant code: LL2023.672-EN-T2-700-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 130x85°
Delivered lumens flux: 6897 lm
Rated input power: 68 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI, AutoDIM, StepDIM
LL2023.672-EN-T2-700-740
Light distribution
[T2] 130x85°
Delivered lumens flux
6897 lm
Rated input power
68 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
98 lm/W
Lamp
8 LED
MacAdam Ellipse
5 SDCM
BUG rating
B2-U0-G1
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000
Variant code: LL2023.672-EN-T2-700-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 130x85°
Delivered lumens flux: 5891 lm
Rated input power: 68 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI, AutoDIM, StepDIM
LL2023.672-EN-T2-700-830
Light distribution
[T2] 130x85°
Delivered lumens flux
5891 lm
Rated input power
68 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
84 lm/W
Lamp
8 LED
MacAdam Ellipse
5 SDCM
BUG rating
B1-U0-G1
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000

Accessories (To be ordered separately)


Accessories (To be ordered separately)


Extras


10 kV

[SP10]

10 kV

External surge protection
NEMA socket - 7 Pin

[NM7]

NEMA socket - 7 Pin

Connectivity
Constant light output

[CLO]

Constant light output

Light output
Class II

[C2]

Class II

Consult the factory
120-277V 50/60Hz

[UNI]

120-277V 50/60Hz

Consult the factory
Double powder coating

[DPC]

Double powder coating

Luminaire body options

Poles (To be ordered separately)



All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Type II, Asymmetric, Side throw
[T2]

Type II, Asymmetric, Side throw

Drive current


700 mA
[700]

700 mA

Colour temperature


3000 K CRI 70
[730]

3000 K CRI 70

3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

Options

Control

Product colours


On/Off
[ONOFF]

On/Off

DALI
[DALI]

DALI

AutoDIM
[AUTO]

AutoDIM

StepDIM
[STEP]

StepDIM

Product colours


Anthracite grey
[HM3]

Anthracite grey

Light grey
[HM4]

Light grey

Custom colour (Please specify RAL code)
[CC]

Custom colour (Please specify RAL code)
