D-LIGHT 1 Module
LL2023.671-EN
Variants
Light distribution
[T2-S] 130° x 85°
Nominal lumens flux
4800 lm, 4460 lm
Power
32 W (700 mA)
Colour temperature
4000 K CRI 70, 3000 K CRI 80
Options
Control
On/Off, 1-10V, DALI, AstroDIM, StepDIM
Input voltage
220-240V 50/60Hz, 120-277V 50/60Hz
Insulation class
Class I, Class II
Product colours
Extras
External surge protection
10 kV
Connectivity
NEMA 7 Socket
Finishing option
Marine grade coating
Light output
Constant light output
Mounting
Direct pole or side bracket mountable. Spigot: Ø60 mm x 100 mm
Tilt angle
-15°/+15°
Housing
Corrosion resistant die-cast aluminum housing
Finishing
Electrostatic powder coating
Fasteners
Stainless steel (grade 304)
Gasket
EPDM gasket (Shore A 20-25)
Lens / Reflector
High reflectance aluminium coating, multifaceted micro reflector
Glass / Diffusor
Bio-based, enriched with bisphenol A diffusor
Impact protection
IK08
Ingress protection
IP66
Wind catching area (EPA)
0.12 m²
Weight
7.08 kg
LED module
Multi-chip high power LEDs on metal-core PCB
Driver
Thermally-separated internal LED driver
Driver surge protection
10/6 kV
Power factor
> 0.95
Through wiring
Single cable entry
Cable
0.5 m of flexible cable
Pole detail
Poles are supplied with flange plate. Flange cover and anchorage can be ordered separately. Embedded base is optional
Downloads
Variants
Light distribution
[T2-S] Asymmetric, Side throw, Short - 130° x 85°
Nominal lumens flux
4800 lm
4460 lm
Power
32 W
Colour temperature
4000 K CRI 70
3000 K CRI 80
Variant code
Variant name
Optic
Nominal lumens flux
Variant code: LL2023.671-EN-T2-S-700-740
Variant name: MILESTONE 4 - 32W - 700mA - 4000K CRI 70
Optic: [T2-S] Asymmetric, Side throw, Short - 130° x 85°
Nominal lumens flux: 4800 lm
Delivered lumens flux
3975 lm
Rated input power
35 W
Efficacy
114 lm/W
Lamp
4 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Variant code: LL2023.671-EN-T2-S-700-830
Variant name: MILESTONE 4 - 32W - 700mA - 3000K CRI 80
Optic: [T2-S] Asymmetric, Side throw, Short - 130° x 85°
Nominal lumens flux: 4460 lm
Delivered lumens flux
3697 lm
Rated input power
35 W
Efficacy
106 lm/W
Lamp
4 LED
MacAdam Ellipse
3 SDCM
BUG rating
B1-U0-G1
Poles
Conical aluminum poles with flange plate
Variant code
Height
Diameter
Spigot diameter
Variant code: PAFK.D114-SC60-H4
Height: 4 m
Diameter: Ø114 mm
Spigot diameter: Ø60 mm
Variant code: PAFK.D114-SC60-H5
Height: 5 m
Diameter: Ø114 mm
Spigot diameter: Ø60 mm
Variant code: PAFK.D122-SC60-H6
Height: 6 m
Diameter: Ø122 mm
Spigot diameter: Ø60 mm
Variant code: PAFK.D148-SC60-H6
Height: 6 m
Diameter: Ø148 mm
Spigot diameter: Ø60 mm
Variant code: PAFK.D165-SC76-H8
Height: 8 m
Diameter: Ø165 mm
Spigot diameter: Ø76 mm
Conical aluminum poles with embedded base
Variant code
Height
Diameter
Spigot diameter
Variant code: PABK.D114-SC60-H4
Height: 4 m
Diameter: Ø114 mm
Spigot diameter: Ø60 mm
Variant code: PABK.D114-SC60-H5
Height: 5 m
Diameter: Ø114 mm
Spigot diameter: Ø60 mm
Variant code: PABK.D122-SC60-H6
Height: 6 m
Diameter: Ø122 mm
Spigot diameter: Ø60 mm
Variant code: PABK.D148-SC60-H6
Height: 6 m
Diameter: Ø148 mm
Spigot diameter: Ø60 mm
Variant code: PABK.D165-SC90-H8
Height: 8 m
Diameter: Ø165 mm
Spigot diameter: Ø90 mm
Descriptions
Variants
Light distribution
Drive current
[T2-S]
Asymmetric, Side throw, Short
Drive current
[700]
700 mA
Colour temperature
[830]
3000 K CRI 80
[740]
4000 K CRI 70
Options
Control
Input voltage
[ONOFF]
On/Off
[DIM]
1-10V
[DALI]
DALI
[ASTRO]
AstroDIM
[STEP]
StepDIM
Input voltage
[EN]
220-240V 50/60Hz
[UNI]
120-277V 50/60Hz
Insulation class
Product colours
[C1]
Class I
[C2]
Class II
Product colours
[HM1]
Black (Textured)
[HM2]
Dark grey (Textured)
[HM3]
Anthracite grey (Textured)
[HM4]
Light grey (Textured)
[HM5]
White (Textured)
[HM6]
Bronze (Textured)
[CC]
Custom Colour (Please specify RAL code)
Extras
External surge protection
Connectivity
[SP10-EN]
10 kV
Connectivity
[NM7]
NEMA 7 Socket
Finishing option
Light output
[MG]
Marine grade coating
Light output
[CLO]
Constant light output
