HANDRA Side - Ø60 mm

NEW
HANDRA Side - Ø60 mmHANDRA Side - Ø60 mm
HANDRA Side - Ø60 mmHANDRA Side - Ø60 mm

LH5007.595-EN

CEIK10IP65Class III
Variants
Light distribution
[SLSH] 30°x55°, [SLSH] 42x54°
Nominal LED lumens flux
156 - 179 lm
Nominal LED power
1 W (350 mA)
Rated luminaire lumens flux
40 - 62 lm
Rated luminaire power
1 W
Colour temperature
2700 K CRI 80, 3000 K CRI 70, 3000 K CRI 80, 4000 K CRI 70, 4000 K CRI 80
BUG rating
B0-U0-G0
Lifetime L90B50 (hour)
>102, 000, >100
Lifetime L80B50 (hour)
>102, 000, >100
Options
Control
On/Off, DALI
Input voltage
3 Vdc (Max) 350 mA
Product colours
Black (Textured)Dark grey (Textured)Anthracite grey (Textured)Light grey (Textured)White (Textured)Bronze (Textured)Custom colour (Please specify RAL code)

Technical details



Certificates
CE
Housing
Corrosion resistant, die-cast, marine grade aluminum housing
Finishing
Chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (grade 304)
Gasket
Liquid gasket
Lens / Reflector
High reflectance aluminium coating
Glass / Diffusor
Custom Design PMMA Diffusor
Impact protection
IK10
Ingress protection
IP65
Insulation class
Class III
Weight
0.05 kg
LED module
High power LEDs on metal-core PCB
Driver
External LED driver
Driver surge protection
1/1 kV
Power factor
> 0.60
Through wiring
Single cable entry
Operating temperature
-25...50°C
Cable
0.2 m of flexible cable

Downloads


Variants


Light distribution
Special linear, Side throw
[SLSH] Special linear, Side throw - 30°x55°
Special linear, Side throw
[SLSH] Special linear, Side throw - 42x54°
Nominal LED lumens flux
156 lm
168 lm
179 lm
Nominal LED power
1 W
Colour temperature
2700 K CRI 80
3000 K CRI 70
3000 K CRI 80
4000 K CRI 70
4000 K CRI 80

Variant code

Variant name

Optic

Nominal LED lumens flux




Variant code: LH5007.595-EN-SLSH-350-730
Variant name: MDBW 1 - 1W - 350mA - 3000K CRI 70
Optic: [SLSH] Special linear, Side throw - 30°x55°
Nominal LED lumens flux: 168 lm
LH5007.595-EN-SLSH-350-730
Nominal LED lumens flux
168 lm
Nominal LED power
1 W
Rated luminaire lumens flux
62 lm
Rated luminaire power
1 W
Luminaire efficacy
62 lm/W
Lamp
1 LED
MacAdam Ellipse
Quarter Bin
Lifetime L90B50 (hour)
>100,000
Lifetime L80B50 (hour)
>100,000
Variant code: LH5007.595-EN-SLSH-350-740
Variant name: Dyno 1 - 1 W - 350 mA - 4000 K CRI 70
Optic: [SLSH] Special linear, Side throw - 42x54°
Nominal LED lumens flux: 179 lm
LH5007.595-EN-SLSH-350-740
Nominal LED lumens flux
179 lm
Nominal LED power
1 W
Rated luminaire lumens flux
48 lm
Rated luminaire power
1 W
Luminaire efficacy
48 lm/W
Lamp
1 LED
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LH5007.595-EN-SLSH-350-827
Variant name: Dyno 1 - 1 W - 350 mA - 2700 K CRI 80
Optic: [SLSH] Special linear, Side throw - 42x54°
Nominal LED lumens flux: 156 lm
Nominal LED lumens flux
156 lm
Nominal LED power
1 W
Rated luminaire lumens flux
40 lm
Rated luminaire power
1 W
Luminaire efficacy
40 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LH5007.595-EN-SLSH-350-830
Variant name: Dyno 1 - 1 W - 350 mA - 3000 K CRI 80
Optic: [SLSH] Special linear, Side throw - 42x54°
Nominal LED lumens flux: 156 lm
Nominal LED lumens flux
156 lm
Nominal LED power
1 W
Rated luminaire lumens flux
40 lm
Rated luminaire power
1 W
Luminaire efficacy
40 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000
Variant code: LH5007.595-EN-SLSH-350-840
Variant name: Dyno 1 - 1 W - 350 mA - 4000 K CRI 80
Optic: [SLSH] Special linear, Side throw - 42x54°
Nominal LED lumens flux: 156 lm
Nominal LED lumens flux
156 lm
Nominal LED power
1 W
Rated luminaire lumens flux
40 lm
Rated luminaire power
1 W
Luminaire efficacy
40 lm/W
Lamp
1 LED
MacAdam Ellipse
4 SDCM
BUG rating
B0-U0-G0
Lifetime L90B50 (hour)
>102,000
Lifetime L80B50 (hour)
>102,000

Accessories (To be ordered separately)


All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Special linear, Side throw
[SLSH]

Special linear, Side throw

Drive current


350 mA
[350]

350 mA

Colour temperature


2700 K CRI 80
[827]

2700 K CRI 80

3000 K CRI 70
[730]

3000 K CRI 70

3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

4000 K CRI 80
[840]

4000 K CRI 80

Options

Control

Input voltage


On/Off
[ONOFF]

On/Off

DALI
[DALI]

DALI

Input voltage


3 Vdc (Max) 350 mA
[CC-3V-350]

3 Vdc (Max) 350 mA

Product colours


Product colours


Black (Textured)
[HM1]

Black (Textured)

Dark grey (Textured)
[HM2]

Dark grey (Textured)

Anthracite grey (Textured)
[HM3]

Anthracite grey (Textured)

Light grey (Textured)
[HM4]

Light grey (Textured)

White (Textured)
[HM5]

White (Textured)

Bronze (Textured)
[HM6]

Bronze (Textured)

Custom colour (Please specify RAL code)
[CC]

Custom colour (Please specify RAL code)
