SPARK

NEW
QUICK-SHIP
IF Design Award 2023
SPARKSPARKSPARK
SPARKSPARKSPARK

LF8040.529-EN

CEUKCAIK07IP66Class III
Variants
Light distribution
[M] 36°, [MN] 24°, [N] 18°, [VN] 8°, [W] 60°
Delivered lumens flux
226 - 727 lm
Rated input power
7 - 9 W
Colour temperature
2700 K CRI 90, 3000 K CRI 80, 3000 K CRI 90
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Options
Product colours
BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
Extras
Light output
Blue Colour Filter, Green Colour Filter, Honeycomb, Orange Colour Filter, Red Colour Filter, Yellow Colour Filter
Mounting options
Pole Mount, Wall Mount
Luminaire body options
Double powder coating

Technical details



Certificates
CE, UKCA
Mounting
Surface mountable via a stationary base (standard), spike andwall-mountable via a bracket (both optional)
Tilt angle
+90°/0°
Rotation angle
0°/+355°
Housing
Corrosion resistant, marine grade aluminum housing
Finishing
Knurled surface in black anodized aluminum and body in chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (AISI 316L)
Gasket
EPDM gasket (Shore A 25-30)
Lens / Reflector
PMMA lens with high optical efficiency
Glass / Diffusor
Tempered safety glass
Impact protection
IK07
Ingress protection
IP66
Input voltage
36 Vdc (Max) 250 mA
Insulation class
Class III
Weight
0.43 kg
LED module
High efficacy COB LED with long time reliability
Driver
Remote LED driver
Through wiring
Single cable entry
Operating temperature
-40...50°C
Cable
0.2 m of flexible cable
Notes
QUICK SHIP: Some variants will be delivered faster. Please consult the factory., For 3000K 90CRI enquries, please consult the factory.

Downloads


Variants


Light distribution
Very narrow
[VN] Very narrow - 8°
Narrow
[N] Narrow - 18°
Medium narrow
[MN] Medium narrow - 24°
Medium
[M] Medium - 36°
Wide
[W] Wide - 60°
Delivered lumens flux
226 lm
243 lm
325 lm
546 lm
575 lm
589 lm
593 lm
606 lm
620 lm
624 lm
638 lm
655 lm
707 lm
711 lm
727 lm
Rated input power
7 W
9 W
Colour temperature
2700 K CRI 90
3000 K CRI 80
3000 K CRI 90

Variant code

Light distribution

Delivered lumens flux

Rated input power

Colour temperature

Control


Variant code: LF8040.529-EN-VN-500-830
Light distribution: [VN] Very narrow - 8°
Delivered lumens flux: 325 lm
Rated input power: 7 W
Colour temperature: 3000 K CRI 80
Control:
Light distribution
[VN] 8°
Delivered lumens flux
325 lm
Rated input power
7 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
46.43 lm/W
Lamp
1 LED
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-VN-500-927
Light distribution: [VN] Very narrow - 8°
Delivered lumens flux: 243 lm
Rated input power: 7 W
Colour temperature: 2700 K CRI 90
Control:
Light distribution
[VN] 8°
Delivered lumens flux
243 lm
Rated input power
7 W
Colour temperature
2700 K CRI 90
Luminaire efficacy
34.65 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-VN-500-930
Light distribution: [VN] Very narrow - 8°
Delivered lumens flux: 226 lm
Rated input power: 7 W
Colour temperature: 3000 K CRI 90
Control:
Light distribution
[VN] 8°
Delivered lumens flux
226 lm
Rated input power
7 W
Colour temperature
3000 K CRI 90
Luminaire efficacy
32.24 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-N-250-830
Light distribution: [N] Narrow - 18°
Delivered lumens flux: 707 lm
Rated input power: 9 W
Colour temperature: 3000 K CRI 80
Control:
LF8040.529-EN-N-250-830
Light distribution
[N] 18°
Delivered lumens flux
707 lm
Rated input power
9 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
78.52 lm/W
Lamp
1 COB
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-N-250-927
Light distribution: [N] Narrow - 18°
Delivered lumens flux: 620 lm
Rated input power: 9 W
Colour temperature: 2700 K CRI 90
Control:
LF8040.529-EN-N-250-927
Light distribution
[N] 18°
Delivered lumens flux
620 lm
Rated input power
9 W
Colour temperature
2700 K CRI 90
Luminaire efficacy
68.87 lm/W
Lamp
1 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-N-250-930
Light distribution: [N] Narrow - 18°
Delivered lumens flux: 589 lm
Rated input power: 9 W
Colour temperature: 3000 K CRI 90
Control:
LF8040.529-EN-N-250-930
Light distribution
[N] 18°
Delivered lumens flux
589 lm
Rated input power
9 W
Colour temperature
3000 K CRI 90
Luminaire efficacy
65.43 lm/W
Lamp
1 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-MN-250-830
Light distribution: [MN] Medium narrow - 24°
Delivered lumens flux: 711 lm
Rated input power: 9 W
Colour temperature: 3000 K CRI 80
Control:
LF8040.529-EN-MN-250-830
Light distribution
[MN] 24°
Delivered lumens flux
711 lm
Rated input power
9 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
79 lm/W
Lamp
1 COB
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-MN-250-927
Light distribution: [MN] Medium narrow - 24°
Delivered lumens flux: 624 lm
Rated input power: 9 W
Colour temperature: 2700 K CRI 90
Control:
LF8040.529-EN-MN-250-927
Light distribution
[MN] 24°
Delivered lumens flux
624 lm
Rated input power
9 W
Colour temperature
2700 K CRI 90
Luminaire efficacy
69.3 lm/W
Lamp
1 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-MN-250-930
Light distribution: [MN] Medium narrow - 24°
Delivered lumens flux: 593 lm
Rated input power: 9 W
Colour temperature: 3000 K CRI 90
Control:
LF8040.529-EN-MN-250-930
Light distribution
[MN] 24°
Delivered lumens flux
593 lm
Rated input power
9 W
Colour temperature
3000 K CRI 90
Luminaire efficacy
65.83 lm/W
Lamp
1 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-M-250-830
Light distribution: [M] Medium - 36°
Delivered lumens flux: 655 lm
Rated input power: 9 W
Colour temperature: 3000 K CRI 80
Control:
LF8040.529-EN-M-250-830
Light distribution
[M] 36°
Delivered lumens flux
655 lm
Rated input power
9 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
72.77 lm/W
Lamp
1 COB
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-M-250-927
Light distribution: [M] Medium - 36°
Delivered lumens flux: 575 lm
Rated input power: 9 W
Colour temperature: 2700 K CRI 90
Control:
LF8040.529-EN-M-250-927
Light distribution
[M] 36°
Delivered lumens flux
575 lm
Rated input power
9 W
Colour temperature
2700 K CRI 90
Luminaire efficacy
63.84 lm/W
Lamp
1 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-M-250-930
Light distribution: [M] Medium - 36°
Delivered lumens flux: 546 lm
Rated input power: 9 W
Colour temperature: 3000 K CRI 90
Control:
LF8040.529-EN-M-250-930
Light distribution
[M] 36°
Delivered lumens flux
546 lm
Rated input power
9 W
Colour temperature
3000 K CRI 90
Luminaire efficacy
60.65 lm/W
Lamp
1 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-W-250-830
Light distribution: [W] Wide - 60°
Delivered lumens flux: 727 lm
Rated input power: 9 W
Colour temperature: 3000 K CRI 80
Control:
Light distribution
[W] 60°
Delivered lumens flux
727 lm
Rated input power
9 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
80.83 lm/W
Lamp
1 COB
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-W-250-927
Light distribution: [W] Wide - 60°
Delivered lumens flux: 638 lm
Rated input power: 9 W
Colour temperature: 2700 K CRI 90
Control:
Light distribution
[W] 60°
Delivered lumens flux
638 lm
Rated input power
9 W
Colour temperature
2700 K CRI 90
Luminaire efficacy
70.91 lm/W
Lamp
1 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LF8040.529-EN-W-250-930
Light distribution: [W] Wide - 60°
Delivered lumens flux: 606 lm
Rated input power: 9 W
Colour temperature: 3000 K CRI 90
Control:
Light distribution
[W] 60°
Delivered lumens flux
606 lm
Rated input power
9 W
Colour temperature
3000 K CRI 90
Luminaire efficacy
67.36 lm/W
Lamp
1 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000

Accessories (To be ordered separately)


Extras


Blue Colour Filter

[BCF]

Blue Colour Filter

Light output
Green Colour Filter

[GCF]

Green Colour Filter

Light output
Honeycomb

[HNY]

Honeycomb

Light output
Orange Colour Filter

[OCF]

Orange Colour Filter

Light output
Red Colour Filter

[RCF]

Red Colour Filter

Light output
Yellow Colour Filter

[YCF]

Yellow Colour Filter

Light output
Pole Mount

[PM]

Pole Mount

Mounting options
Wall Mount

[WM]

Wall Mount

Mounting options
Double powder coating

[DPC]

Double powder coating

Luminaire body options

All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Very narrow
[VN]

Very narrow

Narrow
[N]

Narrow

Medium narrow
[MN]

Medium narrow

Medium
[M]

Medium

Wide
[W]

Wide

Drive current


500 mA
[500]

500 mA

250 mA
[250]

250 mA

Colour temperature


2700 K CRI 90
[927]

2700 K CRI 90

3000 K CRI 80
[830]

3000 K CRI 80

3000 K CRI 90
[930]

3000 K CRI 90

Options

Control

Product colours


Product colours


Black
[HM1]

Black

Dark grey
[HM2]

Dark grey

Anthracite grey
[HM3]

Anthracite grey

Light grey
[HM4]

Light grey

White
[HM5]

White

Bronze
[HM6]

Bronze

Custom colour (Please specify RAL code)
[CC]

Custom colour (Please specify RAL code)
