    PINA Flood

    QUICK-SHIP
    PINA FloodPINA Flood
    PINA FloodPINA Flood

    LF8033.003-EN

    CEUKCAIK06IP65Class I
    Variants
    Light distribution
    [M] 60°, [MN] 36°, [N] 25°, [VN] 10°
    Delivered lumens flux
    368 - 410 lm
    Rated input power
    7.5 W
    Colour temperature
    2700 K CRI 90, 3000 K CRI 90, 4000 K CRI 90
    Options
    Control
    On/Off
    Product colours
    BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
    Extras
    Consult the factory
    120-277V 50/60Hz

    Technical details


    Certificates
    CE, UKCA
    Mounting
    Surface mountable via a stationery base (standard) or spike (optional)
    Tilt angle
    +90°/-80°
    Housing
    Corrosion resistant, marine grade aluminum housing
    Finishing
    Chromate conversion pretreatment followed by electrostatic powder coating
    Fasteners
    Stainless steel (AISI 304 / EN 1.4301 grade)
    Gasket
    Silicone
    Glass / Diffusor
    Tempered safety glass
    Impact protection
    IK06
    Ingress protection
    IP65
    Input voltage
    220-240V 50/60Hz
    Insulation class
    Class I
    Wind catching area (EPA)
    0.01 m²
    Weight
    0.43 kg
    Driver
    Internal LED driver
    Power factor
    > 0.80
    Through wiring
    Single cable entry
    Cable
    0.4 m of flexible cable
    Notes
    This product is supplied without a bulb as standard. The shown lighting distribution and performance are indicative but can change depending on the bulb. Please consult the factory for bulb options and availability., QUICK SHIP: Some variants will be delivered faster. Please consult the factory.

    Downloads

    Variants

    Light distribution
    Very narrow
    [VN] Very narrow - 10°
    Narrow
    [N] Narrow - 25°
    Medium narrow
    [MN] Medium narrow - 36°
    Medium
    [M] Medium - 60°
    Delivered lumens flux
    368 lm
    390 lm
    410 lm
    Rated input power
    7.5 W
    Colour temperature
    2700 K CRI 90
    3000 K CRI 90
    4000 K CRI 90

    Variant code

    Light distribution

    Delivered lumens flux

    Rated input power

    Colour temperature

    Control

    Variant code: LF8033.003-EN-VN-927
    Light distribution: [VN] Very narrow - 10°
    Delivered lumens flux: 368 lm
    Rated input power: 7.5 W
    Colour temperature: 2700 K CRI 90
    Control: On/Off
    LF8033.003-EN-VN-927
    Light distribution
    [VN] 10°
    Delivered lumens flux
    368 lm
    Rated input power
    7.5 W
    Colour temperature
    2700 K CRI 90
    Luminaire efficacy
    49 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-VN-930
    Light distribution: [VN] Very narrow - 10°
    Delivered lumens flux: 390 lm
    Rated input power: 7.5 W
    Colour temperature: 3000 K CRI 90
    Control: On/Off
    LF8033.003-EN-VN-930
    Light distribution
    [VN] 10°
    Delivered lumens flux
    390 lm
    Rated input power
    7.5 W
    Colour temperature
    3000 K CRI 90
    Luminaire efficacy
    52 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-VN-940
    Light distribution: [VN] Very narrow - 10°
    Delivered lumens flux: 410 lm
    Rated input power: 7.5 W
    Colour temperature: 4000 K CRI 90
    Control: On/Off
    LF8033.003-EN-VN-940
    Light distribution
    [VN] 10°
    Delivered lumens flux
    410 lm
    Rated input power
    7.5 W
    Colour temperature
    4000 K CRI 90
    Luminaire efficacy
    55 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-N-927
    Light distribution: [N] Narrow - 25°
    Delivered lumens flux: 368 lm
    Rated input power: 7.5 W
    Colour temperature: 2700 K CRI 90
    Control: On/Off
    LF8033.003-EN-N-927
    Light distribution
    [N] 25°
    Delivered lumens flux
    368 lm
    Rated input power
    7.5 W
    Colour temperature
    2700 K CRI 90
    Luminaire efficacy
    49 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-N-930
    Light distribution: [N] Narrow - 25°
    Delivered lumens flux: 390 lm
    Rated input power: 7.5 W
    Colour temperature: 3000 K CRI 90
    Control: On/Off
    LF8033.003-EN-N-930
    Light distribution
    [N] 25°
    Delivered lumens flux
    390 lm
    Rated input power
    7.5 W
    Colour temperature
    3000 K CRI 90
    Luminaire efficacy
    52 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-N-940
    Light distribution: [N] Narrow - 25°
    Delivered lumens flux: 410 lm
    Rated input power: 7.5 W
    Colour temperature: 4000 K CRI 90
    Control: On/Off
    LF8033.003-EN-N-940
    Light distribution
    [N] 25°
    Delivered lumens flux
    410 lm
    Rated input power
    7.5 W
    Colour temperature
    4000 K CRI 90
    Luminaire efficacy
    55 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-MN-927
    Light distribution: [MN] Medium narrow - 36°
    Delivered lumens flux: 368 lm
    Rated input power: 7.5 W
    Colour temperature: 2700 K CRI 90
    Control: On/Off
    LF8033.003-EN-MN-927
    Light distribution
    [MN] 36°
    Delivered lumens flux
    368 lm
    Rated input power
    7.5 W
    Colour temperature
    2700 K CRI 90
    Luminaire efficacy
    49 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-MN-930
    Light distribution: [MN] Medium narrow - 36°
    Delivered lumens flux: 390 lm
    Rated input power: 7.5 W
    Colour temperature: 3000 K CRI 90
    Control: On/Off
    LF8033.003-EN-MN-930
    Light distribution
    [MN] 36°
    Delivered lumens flux
    390 lm
    Rated input power
    7.5 W
    Colour temperature
    3000 K CRI 90
    Luminaire efficacy
    52 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-MN-940
    Light distribution: [MN] Medium narrow - 36°
    Delivered lumens flux: 410 lm
    Rated input power: 7.5 W
    Colour temperature: 4000 K CRI 90
    Control: On/Off
    LF8033.003-EN-MN-940
    Light distribution
    [MN] 36°
    Delivered lumens flux
    410 lm
    Rated input power
    7.5 W
    Colour temperature
    4000 K CRI 90
    Luminaire efficacy
    55 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-M-927
    Light distribution: [M] Medium - 60°
    Delivered lumens flux: 368 lm
    Rated input power: 7.5 W
    Colour temperature: 2700 K CRI 90
    Control: On/Off
    LF8033.003-EN-M-927
    Light distribution
    [M] 60°
    Delivered lumens flux
    368 lm
    Rated input power
    7.5 W
    Colour temperature
    2700 K CRI 90
    Luminaire efficacy
    49 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-M-930
    Light distribution: [M] Medium - 60°
    Delivered lumens flux: 390 lm
    Rated input power: 7.5 W
    Colour temperature: 3000 K CRI 90
    Control: On/Off
    LF8033.003-EN-M-930
    Light distribution
    [M] 60°
    Delivered lumens flux
    390 lm
    Rated input power
    7.5 W
    Colour temperature
    3000 K CRI 90
    Luminaire efficacy
    52 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM
    Variant code: LF8033.003-EN-M-940
    Light distribution: [M] Medium - 60°
    Delivered lumens flux: 410 lm
    Rated input power: 7.5 W
    Colour temperature: 4000 K CRI 90
    Control: On/Off
    LF8033.003-EN-M-940
    Light distribution
    [M] 60°
    Delivered lumens flux
    410 lm
    Rated input power
    7.5 W
    Colour temperature
    4000 K CRI 90
    Luminaire efficacy
    55 lm/W
    Lamp
    1 LAMP
    MacAdam Ellipse
    5 SDCM

    Accessories (To be ordered separately)

    Accessories (To be ordered separately)

    Related products

    All flux and power values derived following appropriate IES, CIE and applicable standards.
    Descriptions
    Variants

    Light distribution

    Drive current

    Very narrow
    [VN]

    Very narrow

    Narrow
    [N]

    Narrow

    Medium narrow
    [MN]

    Medium narrow

    Medium
    [M]

    Medium

    Drive current

    Lamp
    [L]

    Lamp

    Colour temperature

    2700 K CRI 90
    [927]

    2700 K CRI 90

    3000 K CRI 90
    [930]

    3000 K CRI 90

    4000 K CRI 90
    [940]

    4000 K CRI 90

    Options

    Control

    Product colours

    On/Off
    [ONOFF]

    On/Off

    Product colours

    Black
    [HM1]

    Black

    Dark grey
    [HM2]

    Dark grey

    Anthracite grey
    [HM3]

    Anthracite grey

    Light grey
    [HM4]

    Light grey

    White
    [HM5]

    White

    Bronze
    [HM6]

    Bronze

    Custom colour (Please specify RAL code)
    [CC]

    Custom colour (Please specify RAL code)

    Extras

    Consult the factory

    120-277V 50/60Hz
    [UNI]

    120-277V 50/60Hz
