C-LIGHT ML 4 Module

C-LIGHT ML 4 ModuleC-LIGHT ML 4 Module
C-LIGHT ML 4 ModuleC-LIGHT ML 4 Module

LC2029.674-EN

CEUKCAIK08IP66Class I
Variants
Light distribution
[T2] 130x85°, [T5] 130x100°
Delivered lumens flux
11643 - 16955 lm
Rated input power
137 W
Colour temperature
2700 K CRI 80, 3000 K CRI 80, 4000 K CRI 70, 4000 K CRI 80
BUG rating
B2-U0-G2, B3-U0-G2
Lifetime L90B50 (hour)
>60, 000
Lifetime L80B50 (hour)
>60, 000
Options
Control
On/Off, DALI
Product colours
Anthracite greyLight greyCustom colour (Please specify RAL code)
Extras
Consult the factory
Class II, 120-277V 50/60Hz
Luminaire body options
Double powder coating

Technical details



Certificates
CE, UKCA
Mounting
Catenary wire mounting
Housing
Corrosion resistant, die-cast, marine grade aluminum housing
Finishing
Chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (AISI 304 / EN 1.4301 grade)
Gasket
Silicone
Lens / Reflector
High reflectance aluminium coating, multifaceted micro reflector
Glass / Diffusor
Bio-based, enriched with bisphenol A diffusor
Impact protection
IK08
Ingress protection
IP66
Input voltage
220-240V 50/60Hz
Insulation class
Class I
Weight
9.6 kg
LED module
Multi-chip high power LEDs on metal-core PCB
Driver
Internal LED driver
Driver surge protection
8/6 kV
Power factor
> 0.99
Through wiring
Single cable entry
Operating temperature
-40...50°C
Cable
1 m of halogen-free cable
Notes
This product can be supplied with Insulation class (Class II) upon request. Please contact factory.

Downloads


Variants


Light distribution
Type II, Asymmetric, Side throw
[T2] Type II, Asymmetric, Side throw - 130x85°
Type V, Symmetric
[T5] Type V, Symmetric - 130x100°
Delivered lumens flux
11643 lm
11783 lm
13415 lm
13580 lm
13795 lm
14714 lm
15900 lm
16955 lm
Rated input power
137 W
Colour temperature
2700 K CRI 80
3000 K CRI 80
4000 K CRI 70
4000 K CRI 80

Variant code

Light distribution

Delivered lumens flux

Rated input power

Colour temperature

Control


Variant code: LC2029.674-EN-T2-700-740
Light distribution: [T2] Type II, Asymmetric, Side throw - 130x85°
Delivered lumens flux: 13795 lm
Rated input power: 137 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI
LC2029.674-EN-T2-700-740
Light distribution
[T2] 130x85°
Delivered lumens flux
13795 lm
Rated input power
137 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
100 lm/W
Lamp
16 LED
MacAdam Ellipse
5 SDCM
BUG rating
B3-U0-G2
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000
Variant code: LC2029.674-EN-T2-700-827
Light distribution: [T2] Type II, Asymmetric, Side throw - 130x85°
Delivered lumens flux: 11643 lm
Rated input power: 137 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI
LC2029.674-EN-T2-700-827
Light distribution
[T2] 130x85°
Delivered lumens flux
11643 lm
Rated input power
137 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
85 lm/W
Lamp
16 LED
MacAdam Ellipse
5 SDCM
BUG rating
B2-U0-G2
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000
Variant code: LC2029.674-EN-T2-700-830
Light distribution: [T2] Type II, Asymmetric, Side throw - 130x85°
Delivered lumens flux: 11783 lm
Rated input power: 137 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI
LC2029.674-EN-T2-700-830
Light distribution
[T2] 130x85°
Delivered lumens flux
11783 lm
Rated input power
137 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
86 lm/W
Lamp
16 LED
MacAdam Ellipse
5 SDCM
BUG rating
B2-U0-G2
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000
Variant code: LC2029.674-EN-T2-700-840
Light distribution: [T2] Type II, Asymmetric, Side throw - 130x85°
Delivered lumens flux: 14714 lm
Rated input power: 137 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI
LC2029.674-EN-T2-700-840
Light distribution
[T2] 130x85°
Delivered lumens flux
14714 lm
Rated input power
137 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
107 lm/W
Lamp
16 LED
MacAdam Ellipse
5 SDCM
BUG rating
B3-U0-G2
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000
Variant code: LC2029.674-EN-T5-700-740
Light distribution: [T5] Type V, Symmetric - 130x100°
Delivered lumens flux: 15900 lm
Rated input power: 137 W
Colour temperature: 4000 K CRI 70
Control: On/Off, DALI
Light distribution
[T5] 130x100°
Delivered lumens flux
15900 lm
Rated input power
137 W
Colour temperature
4000 K CRI 70
Luminaire efficacy
116 lm/W
Lamp
16 LED
MacAdam Ellipse
5 SDCM
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000
Variant code: LC2029.674-EN-T5-700-827
Light distribution: [T5] Type V, Symmetric - 130x100°
Delivered lumens flux: 13415 lm
Rated input power: 137 W
Colour temperature: 2700 K CRI 80
Control: On/Off, DALI
Light distribution
[T5] 130x100°
Delivered lumens flux
13415 lm
Rated input power
137 W
Colour temperature
2700 K CRI 80
Luminaire efficacy
97 lm/W
Lamp
16 LED
MacAdam Ellipse
5 SDCM
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000
Variant code: LC2029.674-EN-T5-700-830
Light distribution: [T5] Type V, Symmetric - 130x100°
Delivered lumens flux: 13580 lm
Rated input power: 137 W
Colour temperature: 3000 K CRI 80
Control: On/Off, DALI
Light distribution
[T5] 130x100°
Delivered lumens flux
13580 lm
Rated input power
137 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
99 lm/W
Lamp
16 LED
MacAdam Ellipse
5 SDCM
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000
Variant code: LC2029.674-EN-T5-700-840
Light distribution: [T5] Type V, Symmetric - 130x100°
Delivered lumens flux: 16955 lm
Rated input power: 137 W
Colour temperature: 4000 K CRI 80
Control: On/Off, DALI
Light distribution
[T5] 130x100°
Delivered lumens flux
16955 lm
Rated input power
137 W
Colour temperature
4000 K CRI 80
Luminaire efficacy
123 lm/W
Lamp
16 LED
MacAdam Ellipse
5 SDCM
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000

Extras


Class II

[C2]

Class II

Consult the factory
120-277V 50/60Hz

[UNI]

120-277V 50/60Hz

Consult the factory
Double powder coating

[DPC]

Double powder coating

Luminaire body options

All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Type II, Asymmetric, Side throw
[T2]

Type II, Asymmetric, Side throw

Type V, Symmetric
[T5]

Type V, Symmetric

Drive current


700 mA
[700]

700 mA

Colour temperature


2700 K CRI 80
[827]

2700 K CRI 80

3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

4000 K CRI 80
[840]

4000 K CRI 80

Options

Control

Product colours


On/Off
[ONOFF]

On/Off

DALI
[DALI]

DALI

Product colours


Anthracite grey
[HM3]

Anthracite grey

Light grey
[HM4]

Light grey

Custom colour (Please specify RAL code)
[CC]

Custom colour (Please specify RAL code)
