SPARK ST Duo

NEW
IF Design Award 2023
SPARK ST DuoSPARK ST Duo
SPARK ST DuoSPARK ST Duo

LB8044.529-EN

CEUKCAIK07IP66Class III
Variants
Light distribution
[M] 36°, [MN] 24°, [N] 18°, [VN] 8°, [W] 60°
Delivered lumens flux
519 - 1630 lm
Rated input power
14 - 18 W
Colour temperature
2700 K CRI 90, 3000 K CRI 80, 3000 K CRI 90
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Options
Product colours
BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
Height
60cm, 90cm
Extras
Light output
Blue Colour Filter, Green Colour Filter, Honeycomb, Orange Colour Filter, Red Colour Filter, Yellow Colour Filter
Luminaire body options
Double powder coating

Technical details



Certificates
CE, UKCA
Mounting
Surface mountable
Tilt angle
+90°/0°
Rotation angle
0°/+355°
Housing
Corrosion resistant, marine grade aluminum housing
Finishing
Knurled surface in black anodized aluminum and body in chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (AISI 316L)
Gasket
EPDM gasket (Shore A 25-30)
Lens / Reflector
PMMA lens with high optical efficiency
Glass / Diffusor
Tempered safety glass
Impact protection
IK07
Ingress protection
IP66
Input voltage
36 Vdc (Max) 500 mA
Insulation class
Class III
Weight
1.8 kg
LED module
High efficacy COB LED with long time reliability
Driver
Remote LED driver
Through wiring
Single cable entry
Operating temperature
-40...50°C
Cable
0.4 m of flexible cable
Notes
Please consult factory for combinations of different light distributions., For 3000K 90CRI enquries, please consult the factory.

Downloads


Variants


Light distribution
Very narrow
[VN] Very narrow - 8°
Narrow
[N] Narrow - 18°
Medium narrow
[MN] Medium narrow - 24°
Medium
[M] Medium - 36°
Wide
[W] Wide - 60°
Delivered lumens flux
519 lm
558 lm
748 lm
1092 lm
1149 lm
1178 lm
1186 lm
1212 lm
1240 lm
1247 lm
1276 lm
1413 lm
1422 lm
1455 lm
1630 lm
Rated input power
14 W
18 W
Colour temperature
2700 K CRI 90
3000 K CRI 80
3000 K CRI 90

Variant code

Light distribution

Delivered lumens flux

Rated input power

Colour temperature

Control


Variant code: LB8044.529-EN-VN-1000-830
Light distribution: [VN] Very narrow - 8°
Delivered lumens flux: 748 lm
Rated input power: 14 W
Colour temperature: 3000 K CRI 80
Control:
LB8044.529-EN-VN-1000-830
Light distribution
[VN] 8°
Delivered lumens flux
748 lm
Rated input power
14 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
53.43 lm/W
Lamp
2 COB
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-VN-1000-927
Light distribution: [VN] Very narrow - 8°
Delivered lumens flux: 558 lm
Rated input power: 14 W
Colour temperature: 2700 K CRI 90
Control:
LB8044.529-EN-VN-1000-927
Light distribution
[VN] 8°
Delivered lumens flux
558 lm
Rated input power
14 W
Colour temperature
2700 K CRI 90
Luminaire efficacy
37.1 lm/W
Lamp
2 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-VN-1000-930
Light distribution: [VN] Very narrow - 8°
Delivered lumens flux: 519 lm
Rated input power: 14 W
Colour temperature: 3000 K CRI 90
Control:
LB8044.529-EN-VN-1000-930
Light distribution
[VN] 8°
Delivered lumens flux
519 lm
Rated input power
14 W
Colour temperature
3000 K CRI 90
Luminaire efficacy
39.87 lm/W
Lamp
2 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-N-500-830
Light distribution: [N] Narrow - 18°
Delivered lumens flux: 1413 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control:
LB8044.529-EN-N-500-830
Light distribution
[N] 18°
Delivered lumens flux
1413 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
78.52 lm/W
Lamp
2 COB
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-N-500-927
Light distribution: [N] Narrow - 18°
Delivered lumens flux: 1240 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 90
Control:
LB8044.529-EN-N-500-927
Light distribution
[N] 18°
Delivered lumens flux
1240 lm
Rated input power
18 W
Colour temperature
2700 K CRI 90
Luminaire efficacy
68.87 lm/W
Lamp
2 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-N-500-930
Light distribution: [N] Narrow - 18°
Delivered lumens flux: 1178 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 90
Control:
LB8044.529-EN-N-500-930
Light distribution
[N] 18°
Delivered lumens flux
1178 lm
Rated input power
18 W
Colour temperature
3000 K CRI 90
Luminaire efficacy
65.44 lm/W
Lamp
2 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-MN-500-830
Light distribution: [MN] Medium narrow - 24°
Delivered lumens flux: 1422 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control:
LB8044.529-EN-MN-500-830
Light distribution
[MN] 24°
Delivered lumens flux
1422 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
79 lm/W
Lamp
2 COB
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-MN-500-927
Light distribution: [MN] Medium narrow - 24°
Delivered lumens flux: 1247 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 90
Control:
LB8044.529-EN-MN-500-927
Light distribution
[MN] 24°
Delivered lumens flux
1247 lm
Rated input power
18 W
Colour temperature
2700 K CRI 90
Luminaire efficacy
69.3 lm/W
Lamp
2 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-MN-500-930
Light distribution: [MN] Medium narrow - 24°
Delivered lumens flux: 1186 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 90
Control:
LB8044.529-EN-MN-500-930
Light distribution
[MN] 24°
Delivered lumens flux
1186 lm
Rated input power
18 W
Colour temperature
3000 K CRI 90
Luminaire efficacy
65.89 lm/W
Lamp
2 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-M-500-830
Light distribution: [M] Medium - 36°
Delivered lumens flux: 1630 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control:
LB8044.529-EN-M-500-830
Light distribution
[M] 36°
Delivered lumens flux
1630 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
74 lm/W
Lamp
2 LED
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-M-500-927
Light distribution: [M] Medium - 36°
Delivered lumens flux: 1149 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 90
Control:
LB8044.529-EN-M-500-927
Light distribution
[M] 36°
Delivered lumens flux
1149 lm
Rated input power
18 W
Colour temperature
2700 K CRI 90
Luminaire efficacy
63.84 lm/W
Lamp
2 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-M-500-930
Light distribution: [M] Medium - 36°
Delivered lumens flux: 1092 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 90
Control:
LB8044.529-EN-M-500-930
Light distribution
[M] 36°
Delivered lumens flux
1092 lm
Rated input power
18 W
Colour temperature
3000 K CRI 90
Luminaire efficacy
60.76 lm/W
Lamp
2 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-W-500-830
Light distribution: [W] Wide - 60°
Delivered lumens flux: 1455 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 80
Control:
Light distribution
[W] 60°
Delivered lumens flux
1455 lm
Rated input power
18 W
Colour temperature
3000 K CRI 80
Luminaire efficacy
80.83 lm/W
Lamp
2 COB
MacAdam Ellipse
4 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-W-500-927
Light distribution: [W] Wide - 60°
Delivered lumens flux: 1276 lm
Rated input power: 18 W
Colour temperature: 2700 K CRI 90
Control:
Light distribution
[W] 60°
Delivered lumens flux
1276 lm
Rated input power
18 W
Colour temperature
2700 K CRI 90
Luminaire efficacy
70.91 lm/W
Lamp
2 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000
Variant code: LB8044.529-EN-W-500-930
Light distribution: [W] Wide - 60°
Delivered lumens flux: 1212 lm
Rated input power: 18 W
Colour temperature: 3000 K CRI 90
Control:
Light distribution
[W] 60°
Delivered lumens flux
1212 lm
Rated input power
18 W
Colour temperature
3000 K CRI 90
Luminaire efficacy
67.33 lm/W
Lamp
2 COB
MacAdam Ellipse
3 SDCM
Lifetime L90B50 (hour)
>50000
Lifetime L80B50 (hour)
>50000

Accessories (To be ordered separately)


Extras


Blue Colour Filter

[BCF]

Blue Colour Filter

Light output
Green Colour Filter

[GCF]

Green Colour Filter

Light output
Honeycomb

[HNY]

Honeycomb

Light output
Orange Colour Filter

[OCF]

Orange Colour Filter

Light output
Red Colour Filter

[RCF]

Red Colour Filter

Light output
Yellow Colour Filter

[YCF]

Yellow Colour Filter

Light output
Double powder coating

[DPC]

Double powder coating

Luminaire body options

All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Very narrow
[VN]

Very narrow

Narrow
[N]

Narrow

Medium narrow
[MN]

Medium narrow

Medium
[M]

Medium

Wide
[W]

Wide

Drive current


500 mA
[500]

500 mA

Colour temperature


2700 K CRI 90
[927]

2700 K CRI 90

3000 K CRI 80
[830]

3000 K CRI 80

3000 K CRI 90
[930]

3000 K CRI 90

Options

Control

Product colours


Product colours


Black
[HM1]

Black

Dark grey
[HM2]

Dark grey

Anthracite grey
[HM3]

Anthracite grey

Light grey
[HM4]

Light grey

White
[HM5]

White

Bronze
[HM6]

Bronze

Custom colour (Please specify RAL code)
[CC]

Custom colour (Please specify RAL code)
