    LUMA

    UPCOMING
    LUMALUMALUMALUMA

    LB6076.910-EN

    CEUKCAIK07IP65Class I

    Downloads

    LUMALUMALUMALUMA
    Light distribution
    [T3] , [T4]
    Luminaire luminous flux
    320 - 751 lm
    Rated input power
    5 - 10 W
    CCT
    2700K, 3000K, 4000K
    CRI
    Ra80
    Control
    On/Off, DALI
    Product colours
    BlackDark greyAnthracite greyLight greyWhiteBronzeCustom colour (Please specify RAL code)
    Height
    50cm, 1m, Custom height (Please specify)
    Luminaire efficacy
    64 - 75 lm/W
    Colour deviation
    3 SDCM
    Housing
    Marine grade aluminum housing
    Driver
    Integral LED driver
    Input voltage
    220-240V 50/60Hz
    Configurator
    Project name
    Type
    Quantity
    Date
    Note
    Variant order code

    LB6076.910-EN-___-___-___-___-EN-C1-___-___




    Variants
    Light distribution
    [T3]
    Type III, Asymmetric, Side throw
    [T4]
    Type IV, Asymmetric, Forward throw

    Rated input power
    [350]
    5 W
    [700]
    10 W

    Colour temperature
    [827]
    2700 K CRI 80
    [830]
    3000 K CRI 80
    [840]
    4000 K CRI 80
    Options
    Control
    [ONOFF]
    On/Off
    [DALI]
    DALI

    Product colours
    [HM1]Black
    Black
    [HM2]Dark grey
    Dark grey
    [HM3]Anthracite grey
    Anthracite grey
    [HM4]Light grey
    Light grey
    [HM5]White
    White
    [HM6]Bronze
    Bronze
    [CC]Custom colour (Please specify RAL code)
    Custom colour (Please specify RAL code)

    Height
    [H00.50]
    50cm
    [H01]
    1m
    [HC]
    Custom height (Please specify)


    Technical details


    Certificates
    CE, UKCA
    Mounting
    Surface mountable
    Finishing
    Chromate conversion pretreatment followed by electrostatic powder coating
    Fasteners
    Stainless steel (AISI 304 / EN 1.4301 grade)
    Gasket
    Liquid silicone
    Glass / Diffusor
    Tempered safety glass
    Impact protection
    IK07
    Ingress protection
    IP65
    Insulation class
    Class I
    Operating temperature
    -40...50°C

    Accessories (To be ordered separately)

    Accessories (To be ordered separately)

    All flux and power values derived following appropriate IES, CIE and applicable standards.
    Descriptions
    Variants

    Light distribution

    Drive current

    Type III, Asymmetric, Side throw
    [T3]

    Type III, Asymmetric, Side throw

    Type IV, Asymmetric, Forward throw
    [T4]

    Type IV, Asymmetric, Forward throw

    Drive current

    350 mA
    [350]

    350 mA

    700 mA
    [700]

    700 mA

    Colour temperature

    2700 K CRI 80
    [827]

    2700 K CRI 80

    3000 K CRI 80
    [830]

    3000 K CRI 80

    4000 K CRI 80
    [840]

    4000 K CRI 80

    Options

    Control

    Product colours

    On/Off
    [ONOFF]

    On/Off

    DALI
    [DALI]

    DALI

    Product colours

    Black
    [HM1]

    Black

    Dark grey
    [HM2]

    Dark grey

    Anthracite grey
    [HM3]

    Anthracite grey

    Light grey
    [HM4]

    Light grey

    White
    [HM5]

    White

    Bronze
    [HM6]

    Bronze

    Custom colour (Please specify RAL code)
    [CC]

    Custom colour (Please specify RAL code)
