LB6062.693-EN

CEIK08IP65Class I
Variants
Light distribution
[SYM-4L] 360°
Nominal LED lumens flux
260 - 270 lm
Nominal LED power
8 W (700 mA)
Rated luminaire lumens flux
124 - 133 lm
Rated luminaire power
10 W
Colour temperature
3000 K CRI 80, 4000 K CRI 70
BUG rating
B0-U0-G1
Lifetime L90B50 (hour)
>60, 000
Lifetime L80B50 (hour)
>60, 000
Options
Control
On/Off
Input voltage
220-240V 50/60Hz, 120-277V 50/60Hz
Insulation class
Class I
Product colours
Black (Textured)Dark grey (Textured)Anthracite grey (Textured)Light grey (Textured)White (Textured)Bronze (Textured)Custom Colour (Please specify RAL code)
Extras
Finishing options
Marine grade coating

Technical details



Mounting
Surface mountable
Housing
Corrosion resistant, marine grade aluminium head combined with special wood body
Finishing
Chromate conversion pretreatment followed by electrostatic powder coating
Fasteners
Stainless steel (grade 304)
Gasket
Liquid silicone
Glass / Diffusor
UV stable, bio-based polycarbonate diffusor
Impact protection
IK08
Ingress protection
IP65
Weight
5.69 kg
LED module
High power LEDs on metal-core PCB
Driver
Internal LED driver
Driver surge protection
1/1 kV
Power factor
> 0.91
Through wiring
Single cable entry
Operating temperature
-25...50°C
Cable
0.5 m of flexible cable

Downloads


Variants


Light distribution
Symmetric, 360°, Special effect: 4 lines
[SYM-4L] Symmetric, 360°, Special effect: 4 lines - 360°
Nominal LED lumens flux
260 lm
270 lm
Nominal LED power
8 W
Colour temperature
3000 K CRI 80
4000 K CRI 70

Variant code

Variant name

Optic

Nominal LED lumens flux




Variant code: LB6062.693-EN-SYM-4L-700-740
Variant name: LED 1 - 8W - 700 mA - 4000K CRI 70
Optic: [SYM-4L] Symmetric, 360°, Special effect: 4 lines - 360°
Nominal LED lumens flux: 270 lm
LB6062.693-EN-SYM-4L-700-740
Nominal LED lumens flux
270 lm
Nominal LED power
8 W
Rated luminaire lumens flux
133 lm
Rated luminaire power
10 W
Luminaire efficacy
13 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G1
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000
Variant code: LB6062.693-EN-SYM-4L-700-830
Variant name: LED 1 - 8W - 700 mA - 3000K CRI 80
Optic: [SYM-4L] Symmetric, 360°, Special effect: 4 lines - 360°
Nominal LED lumens flux: 260 lm
LB6062.693-EN-SYM-4L-700-830
Nominal LED lumens flux
260 lm
Nominal LED power
8 W
Rated luminaire lumens flux
124 lm
Rated luminaire power
10 W
Luminaire efficacy
12 lm/W
Lamp
1 LED
MacAdam Ellipse
3 SDCM
BUG rating
B0-U0-G1
Lifetime L90B50 (hour)
>60,000
Lifetime L80B50 (hour)
>60,000

Accessories (Included)


All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions
Variants

Light distribution

Drive current


Symmetric, 360°, Special effect: 4 lines
[SYM-4L]

Symmetric, 360°, Special effect: 4 lines

Drive current


700 mA
[700]

700 mA

Colour temperature


3000 K CRI 80
[830]

3000 K CRI 80

4000 K CRI 70
[740]

4000 K CRI 70

Options

Control

Input voltage


On/Off
[ONOFF]

On/Off

Input voltage


220-240V 50/60Hz
[EN]

220-240V 50/60Hz

120-277V 50/60Hz
[UNI]

120-277V 50/60Hz

Insulation class

Product colours


Class I
[C1]

Class I

Product colours


Black (Textured)
[HM1]

Black (Textured)

Dark grey (Textured)
[HM2]

Dark grey (Textured)

Anthracite grey (Textured)
[HM3]

Anthracite grey (Textured)

Light grey (Textured)
[HM4]

Light grey (Textured)

White (Textured)
[HM5]

White (Textured)

Bronze (Textured)
[HM6]

Bronze (Textured)

Custom Colour (Please specify RAL code)
[CC]

Custom Colour (Please specify RAL code)

Extras

Finishing options


Marine grade coating
[MG]

Marine grade coating
