Name: DRAGO Wood Side
Brand: HEPER
SKU: LB6048.585-EN-WO
Availability: InStock

Light distribution

[SLS] 145x45°, [SLS-FG] 158x60°

Luminaire luminous flux

307 - 791 lm

Rated input power

5 - 10 W

CCT

2700K, 3000K, 4000K

CRI

Ra80

Control

On/Off, DALI

Product colours

Height

50cm, 80cm, 1m, Custom height (Please specify)

Extras

Consult the factory

120-277V 50/60Hz

Luminaire body options

Double powder coating

Luminaire efficacy

52 - 93 lm/W

Colour deviation

3 SDCM

Lifetime L90B50 (hour)

>42, 000

Housing

Marine grade aluminum housing

Driver

Integral LED driver

Input voltage

220-240V 50/60Hz

Notes

For Wood-Look options, only the body part will be covered as the chosen texture. The head will be painted with HM2 standard colour.

Configurator

Project name

Type

Quantity

Date

Note

Variant order code

LB6048.585-EN-WO-_-_-_-_-EN-C1-_-_-_-_

Variants required

Variants

Light distribution

[SLS]
Special linear, Side throw
145x45°

[SLS-FG]
Special linear, Side throw - Frosted Glass
158x60°

Rated input power

[350]
5 W

[700]
10 W

Colour temperature

[827]
2700 K CRI 80

[830]
3000 K CRI 80

[840]
4000 K CRI 80

Options

Control

[ONOFF]
On/Off

[DALI]
DALI

Product colours

[WLAO]

Wood-Look: Ash Oak

[WLAS]

Wood-Look: Alpine Spruce

[WLBF]

Wood-Look: Brown Fir

[WLRM]

Wood-Look: Red Mahogany

[WLSO]

Wood-Look: Sienna Oak

Height

[H00.50]
50cm

[H00.80]
80cm

[H01]
1m

[HC]
Custom height (Please specify)

Extras

Consult the factory

[UNI]
120-277V 50/60Hz

Luminaire body options

[DPC]
Double powder coating

Variants required

Technical details

Certificates

CE, UKCA, DarkSky Approved

Mounting

Surface mountable

Finishing

Chromate conversion pretreatment followed by electrostatic powder coating

Fasteners

Stainless steel (AISI 304 / EN 1.4301 grade)

Gasket

Liquid silicone

Lens / Reflector

High reflectance aluminium coating, multifaceted micro reflector

Glass / Diffusor

Tempered safety glass

Impact protection

IK08

Ingress protection

IP66

Insulation class

Class I

Weight

4.5 kg (0.8 m)

LED module

High power LEDs on metal-core PCB

Driver surge protection

1/1 kV

Power factor

> 0.90

Through wiring

Single cable entry

Operating temperature

-40...50°C

Cable

0.2 m of flexible cable

Packing box dimensions

15*20*85 cm (0.8 m)

Accessories (To be ordered separately)

Anchorages

628I000

Technical drawing

0.2 MB PDF

Extras

[UNI]

120-277V 50/60Hz

Consult the factory

[DPC]

Double powder coating

Luminaire body options

All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions

Variants

Light distribution

Drive current

[SLS]

Special linear, Side throw

[SLS-FG]

Special linear, Side throw - Frosted Glass

Drive current

[350]

350 mA

[700]

700 mA

Colour temperature

[827]

2700 K CRI 80

[830]

3000 K CRI 80

[840]

4000 K CRI 80

Options

Control

Product colours

[ONOFF]

On/Off

[DALI]

DALI

Product colours

[WLAO]

Wood-Look: Ash Oak

[WLAS]

Wood-Look: Alpine Spruce

[WLBF]

Wood-Look: Brown Fir

[WLRM]

Wood-Look: Red Mahogany

[WLSO]

Wood-Look: Sienna Oak

DRAGO Wood Side

LB6048.585-EN-WO
