CARINA AFX Mini

Name: CARINA AFX Mini
Brand: HEPER
SKU: LB6033.891-EN
Availability: InStock

UPCOMING

LB6033.891-EN

Downloads

Photometry files (IES)

2.26 MB ZIP

Technical drawing

0.14 MB PDF

Technical drawing (Image)

Light distribution

[T1] , [T2] , [T2-2] , [T3] , [T4]

Luminaire luminous flux

204 - 1088 lm

Rated input power

5 - 14 W

CCT

2700K, 3000K, 4000K

CRI

Ra80

Control

On/Off, DALI *

Product colours

Height

Extras

Consult the factory

120-277V 50/60Hz

* Please check the specific variant for each control type.

Luminaire efficacy

41 - 78 lm/W

Colour deviation

3 SDCM

Lifetime L90B50 (hour)

>102, 000

Housing

Marine grade aluminum housing

Driver

Integral LED driver

Input voltage

220-240V 50/60Hz

Configurator

Project name

Type

Quantity

Date

Note

Variant order code

LB6033.891-EN-_-_-_-_-EN-C1-_-H01-_

Variants

Light distribution

[T1]
Type I, Asymmetric, Side throw

[T2]
Type II, Asymmetric, Side throw

[T2-2]
Type II, Asymmetric, Side throw

[T3]
Type III, Asymmetric, Side throw

[T4]
Type IV, Asymmetric, Forward throw

Rated input power

[350]
5 W

[700]
10 W

[1050]
14 W

Colour temperature

[827]
2700 K CRI 80

[830]
3000 K CRI 80

[840]
4000 K CRI 80

Options

Control

[ONOFF]
On/Off

[DALI]
DALI

Product colours

[HM1]

Black

[HM2]

Dark grey

[HM3]

Anthracite grey

[HM4]

Light grey

[HM5]

White

[HM6]

Bronze

[CC]

Custom colour (Please specify RAL code)

Height

[H01]
1m

Extras

Consult the factory

[UNI]
120-277V 50/60Hz

Technical details

Certificates

CE, UKCA

Mounting

Surface mountable

Finishing

Chromate conversion pretreatment followed by electrostatic powder coating

Fasteners

Stainless steel (AISI 304 / EN 1.4301 grade)

Lens / Reflector

PMMA lens with high optical efficiency

Glass / Diffusor

Tempered safety glass

Impact protection

IK07

Ingress protection

IP65

Insulation class

Class I

LED module

High power LEDs on metal-core PCB

Driver surge protection

1/1 kV

Power factor

> 0.90

Through wiring

Single cable entry

Cable

0.2 m of flexible cable

Accessories (To be ordered separately)

Anchorages

612J014

Technical drawing

0.22 MB PDF

Extras

[UNI]

120-277V 50/60Hz

Consult the factory

All flux and power values derived following appropriate IES, CIE and applicable standards.

Descriptions

Variants

Light distribution

Drive current

[T1]

Type I, Asymmetric, Side throw

[T2]

Type II, Asymmetric, Side throw

[T2-2]

Type II, Asymmetric, Side throw

[T3]

Type III, Asymmetric, Side throw

[T4]

Type IV, Asymmetric, Forward throw

Drive current

[350]

350 mA

[700]

700 mA

[1050]

1050 mA

Colour temperature

[827]

2700 K CRI 80

[830]

3000 K CRI 80

[840]

4000 K CRI 80

Options

Control

Product colours

[ONOFF]

On/Off

[DALI]

DALI

Product colours

[HM1]

Black

[HM2]

Dark grey

[HM3]

Anthracite grey

[HM4]

Light grey

[HM5]

White

[HM6]

Bronze

[CC]

Custom colour (Please specify RAL code)
